LS ULTRACAPACITOR
New-generation Energy Storage Devices with
Great Power and Reliability
LS Mtron Hi-tech center, 39, 1
2020
LS Mtron, Ltd. All right reserved Se
Vision Statement
In order to become a leader in the competitive global market LG has been divided into three
business groups based upon their core competencies, Industrial Electric-Electronic Energy &
Materials(LS), Electronic & Chemical(LG), and Energy & Retail(GS).
Industrial Electric·Electronic,
Energy & Material
Electronic & Chemical
Energy & Retail
INNOVATIVE TECHNOLOGY PARTNER - LS Mtron
LS Mtron’s mission is to grow into a company that provides market leading solutions while devloping a
workplace where its employee can achieve their dreams. All employees of LS Mtron stand behind the vision
of becoming an Innovative Technology Partner and work tirelessly to make LS Mtron a world-class company
LS Mtron will secure world-class core technologies to find and implement the most efficient solutions based
on a market knowledge that can meet the challanges of our today’s markets We will work hand-in-hand with
our customers in order to grow into a global leader.
Business of LS Mtron
Component Machinery
∙ Ultracapacitor ∙ Tractor
∙ Electronic Parts(Connectors / Antenna) ∙ Injection Molding Machine
∙ Track Shoes
Green Energy
Transportation
LS ULTRACAPACITOR
LS Ultracapacitor energy storage devices are positioned between
conventional electrolytic capacitors and rechargeable batteries.
LS Ultracapacitors feature high power, high energy, reliability and long life
which enables use in a variety of applications such as back-up power,
auxiliary power, instantaneous power compensation and peak power compensation.
· Rated voltage : up to 3.0V
· High power performance (vs. Battery)
· High energy performance (vs. Conventional electrolytic capacitor)
· Environmentally friendly
· Maintenance-free
o o
· Wide operating temperature range (-40 C ~ +65 C)
06 C h a r g e t h e , W o r l d
Power Quality
Automation
L S U l t r a c a p a c i t o r 07
Introduction to LS Ultracapacitor Technology
Structure
An Ultracapacitor consists of two electrodes immersed in an electrolyte and
a separator which prevents the charge from moving between two electrodes of opposite polarity.
Separator
Porous
Electrolyte Current
Carbon
Electrode Electrolyte Collector
Separator
Seal
Porous Carbon
∙ LS Ultracapacitor Cylindrical Type Electrode
LS Mtron provides optimal package design to provide the best in performance and reliability.
High Energy & High Power
Ultracapacitors are unique energy storage devices offering high power and high energy simultaneously, compared with
conventional electrolytic capacitors and batteries. The high energy stored by Ultracapacitors in comparison to conventional
electrolytic capacitors is derived from activated carbon electrode material having the extremely high surface area and the
short distance of charge separation created by the opposite charges in the interface between electrode and electrolyte.
Activated Carbon Electrode Activated Carbon Electrode
Electrolyte Electrolyte
Discharge
Pore Pore
Charge
High power, long shelf and cycle life performance of Ultracapacitors originate in the energy storage mechanism differing from
batteries. With batteries, energy is stored and released via chemical reaction inside electrode material that causes degradation
of the entire system. On the other hand, Ultracapacitors use physical charge separation phenomena between the charge on
an electrode and ions in electrolyte at the interface. Since the charge and discharge processes are purely physical and highly
reversible, Ultracapacitors can release energy much faster and with more power compared to batteries which rely on slow
chemical reactions and can be cycled hundreds of thousands of times without significant effect on performance.
Ultracapacitor
Energy density(Wh/kg)
dashed lines are isotherms of
Hybrid capacitors characteristic time constant
Power density(W/kg)
08 C h a r g e t h e , W o r l d
Ultracapacitor VS LIB
Ultracapacitor Li-ion Battery
Fast and Versatile High Energy
Physical absorption-desorption Chemical reaction
• Specific energy : ~15 W·h/kg • Specific energy : ~200 W·h/kg
• Operation Temperature : -40 ~ 85oC • Operation Temperature : 0 ~ 45oC
• Charge/discharge efficiency : 99.2 ~ 99.8 % • Charge/discharge efficiency : 80–90%
• Specific Power : ~ 18 kW/kg • Specific Power : ~0.2 ~ 0.4 kW/kg
• Cycle durability : 1000k Cycles • Cycle durability : 0.4k Cycles (100% DoD basis)
∙ Ultracapacitor ∙ Li-ion Battery
Ultracapacitor + Li-ion Battery
By combining Ultracapacitor and Li-ion battery
Ultracapacitor provides substantial benefits in terms of performances
battery life and energy economy
• To improve the application efficiency and energy economy over variable
operating conditions
• To assure reliable performance and fast response even with battery degradation
• To extend battery life by shaving peak load
L S U l t r a c a p a c i t o r 09
Cell LS Mtron has more than 45 types of cells in mass production
22Φ Series PCB mounting type cell
Rated Capa Max. Max. Leakage Max.
Series Voltage citance Part No. ESR(DC) Current Current Stored Energy Weight Dimension
Type
V F mΩ A mA Wh kg Φ x mm
100 LSUC 002R8S 0100F EA 9.0 74Products
Lug & Snap-in Terminal Type
• 22/33/35Φ Series Cell
• Snap-in (100F/ 120F) • Lug (320F ~ 600F) • Snap-in
(4pin, 350F ~ 720F)
Cylindrical Terminal Type
• Short Screw (ST01) • Weldable (WT01) • Long Screw (LT01) • Long Screw (LT02)
• 60Φ Series Cell ※M16 Terminal ※M12 Terminal
Cell/Module Part No. Rule
LS R F ( )
• Voltage • Capacitance • Internal Code Ⅱ
• Product(Cell) • Cell Type(Snap-in) • Internal Code Ⅰ
- Code C - Code S
• Product(Module) • Cell Type(Lug)
- Code M - Code L
• Cell Type (Cylindrical)
• Code U
- Code C
L S U l t r a c a p a c i t o r 11Module LS Mtron has more than 20 types of modules in mass production
PCB type series PCB type Series is modules built up with 22Φ & 33Φ series cells on PCB board
Max.
Rated Capa Max. Continuous Leakage Stored
Part Voltage citance ESR(DC) Current Current Energy Weight Dimension
No. Balancing Monitoring
V F mΩ A mA Wh kg L x W x H (mm)
LSUM 016R8L 0058F EA 16.8 58 22 20CTC Description
CTC (Cell to Cell) series module can be made up with connected cells (60Φ Series cell) at customer`s request
The CTC module can be made from 16V up to 108V without additional development with extendable module case
L
418
Monitoring for CTC series module
Temperature Temperature Cell voltage
Connector Balancing
sensor interface monitoring
NTC Thermistor Analog 4pin OVA(Optional) Active or Passive
CTC series CTC (Cell To Cell) series module is available from 16V to 108V, is extendable and customizable without additional costs to the customer
Adapted Cell Max.
Rated Capa Max. Continuous Leakage Stored
Part Voltage citance ESR(DC) Current Current Energy Weight Dimension
No. Rated Voltage Capacitance
Series
V F V F mΩ A mA Wh kg L x W x H (mm)
LSUM 048R6C 0066F EA YJ 18 48.6 66 7.2 160 < 2.7 (Active) 21.7 10.3 279 x 418 x 71
1200
LSUM 064R8C 0050F EA YJ 24 64.8 50 9.6 130 < 27 (Passive) 29.2 13.2 362 x 418 x 71
LSUM 048R6C 0083F EA YJ 18 48.6 83 6.1 180 < 3.0 (Active) 27.2 11.5 312 x 418 x 71
1500
LSUM 064R8C 0062F EA YJ 24 64.8 62 8.1 140 < 27 (Passive) 36.2 14.8 406 x 418 x 71
2.7
LSUM 048R6C 0111F EA YJ 18 48.6 111 5.9 180 < 4.0 (Active) 36.4 13.5 363 x 418 x 71
2000
LSUM 064R8C 0083F EA YJ 24 64.8 83 7.8 150 < 27 (Passive) 48.4 17.5 474 x 418 x 71
LSUM 048R6C 0166F EA YJ 18 48.6 166 5.0 200 < 5.0 (Active) 54.5 17.2 471 x 418 x 71
3000
LSUM 064R8C 0125F EA YJ 24 64.8 125 6.7 160 < 27 (Passive) 72.9 22.5 618 x 418 x 71
< 3.0 (Active)
LSUM 016R2C 0250F EA AG 1500 250 2.0 150 9.1 3.9 311 x 166 x 70
< 27 (Passive)
2.7 6 16.2
< 5.0 (Active)
LSUM 016R2C 0500F EA AG 3000 500 1.7 200 18.2 5.9 470 x 166 x 70
< 27 (Passive)
LSUM 048R6C 0166F EA YJ LSUM 016R2C 0500F EA AG LSUM 016R2C 0250F EA AG
L S U l t r a c a p a c i t o r 13Ultracapacitor Biz. History
Longest history in the ultracapacitor industry
LS ultracapacitor has 18 years of history in the ultracapacitor industry
June. 2020
Mass production of
Jan. 2018 3V 3400F cell
Mass production of
3V 3000F cell
Jan. 2017
Mass production of
2.85V 3400F cell
Mar. 2016
Mass production of
3V medium series cells
(PCB type)
Jan. 2014
Development of
Cell to Cell connection
Module
Feb. 2013
Move to LS Mtron Hi-Tech
Center with production line
automated and expanded
Dec. 2008
LS Mtron separated from
LS Cable bringing UC business
division
Dec. 2006
Set up of mass
production line at
LS Gumi factory
May. 2005
Development of
2.8V 3000F EDLC
Sep. 2002
Research and
Development kick start at
LG Cable
14 C h a r g e t h e , W o r l dMarkets for LS Ultracapacitors
AGV Wind Turbine
• Numerous charge & discharge cycles, • Maintenance free in all environments
long life span and long service life
• Peak power shaving, minimizing power • Ultra-safe, eliminating concerns for fire
infrastructure investment or explosion
• Energy saving
Power Quality Solution (UPS) Hybrid Heavy Equipment
• Instant back up for voltage sag or dip • Peak power shaving, downsizing motor
• Maintenance free for up to 20 years and engine requirement
• Ultra-safe, eliminating concerns for fire • Improve fuel economy and meet emission
or explosion regulations
• Long service life and maintenance free
Passenger Car and Vehicle Transportation
• Stabilize DC power supply and extend • Numerous charge & discharge cycles,
battery life maintenance free
• Improve fuel economy by reducing • Capture regenerative braking energy,
alternator loadings improving energy efficiency
• Jumpstart in all seasons • Ultra-safe, eliminating concerns for fire
or explosion
Hybrid Harbor Crane HEV (Hybrid Electric Vehicle)
• Peak shaving and reduction, improving • Provide peak power, extending battery life
crane reliability • Capture regenerative braking energy
• Significant savings in power infrastructure • Jumpstart in all seasons
investment
• Long term return in energy savings
Photovoltaic and Solar Lighting Etc.
• Provides a reliable ESS solution in • Adaptable and serviceable in all
extreme environments environments
• Long service life and maintenance free • Maintenance free, excellent investment
return
• Instant and huge power supply
CERTIFICATE OF COMPLIANCE
Certificate Number 20180514-MH46367
Report Reference MH46367-20081210
Issue Date 2018-MAY-14
This is to certify that the Quality Management System of
Issued to: LS MTRON LTD
LS MTRON LTD.
LS Mtron Hi-Tech Center, 39, LS-ro 116beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14118, Ls Mtron Hi-Tech Center
Korea 116, Ls-Ro, Dongan-Gu
Anyang-Si Gyeonggi-Do 431-831 KOREA
applicable to
Design and manufacturing of energy-storage devices This is to certify that COMPONENT - CAPACITORS, ELECTROCHEMICAL
has been assessed and registered by representative samples of See addendum page for models
NQA, Warwick House, Houghton Hall Park, Houghton Regis, Dunstable LU5 5ZX, Bedfordshire,
England
against the provisions of
Have been investigated by UL in accordance with the
Standard(s) indicated on this Certificate.
IATF 16949 : 2016
Standard(s) for Safety: UL 810A - Standard for: Safety for Electrochemical
Capacitors
This registration is subject to the company maintaining a quality management system, to the above
standard, which will be monitored by NQA Additional Information: See the UL Online Certifications Directory at
www.ul.com/database for additional information
Only those products bearing the UL Certification Mark should be considered as being covered by UL's
Certification and Follow-Up Service.
NQA Certificate No: T 5642/3
IATF Certificate No: 0337127 The UL Recognized Component Mark generally consists of the manufacturer’s identification and catalog
Date: 08 October 2018 number, model number or other product designation as specified under “Marking” for the particular
Managing Director Valid Until: 07 October 2021 Recognition as published in the appropriate UL Directory. As a supplementary means of identifying products
Version: 2 that have been produced under UL’s Component Recognition Program, UL’s Recognized Component Mark:
, may be used in conjunction with the required Recognized Marks. The Recognized Component Mark is
required when specified in the UL Directory preceding the recognitions or under “Markings” for the individual
recognitions.
Recognized components are incomplete in certain constructional features or restricted in performance
capabilities and are intended for use as components of complete equipment submitted for investigation rather
than for direct separate installation in the field. The final acceptance of the component is dependent upon its
installation and use in complete equipment submitted to UL LLC.
Look for the UL Certification Mark on the product.
Reproduction of the IATF 'globe' logo in any form is strictly prohibited by copyright
Bruce Mahrenholz, Director North American Certification Program
UL LLC
Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please
NQA is a trading name of NQA Certification Limited, Registration No. 09351758. Registered Office: Warwick House, Houghton Hall Park, Houghton Regis, Dunstable LU5 5ZX.
contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/
This certificate is the property of NQA and must be returned on request.
Revision Date: Feb 2017 Page 1 of 1 Issue 5
Page 1 of 2
• IATF 16949 • ISO 14001:2015 • OHSAS18001:2007 • UL Certification
L S U l t r a c a p a c i t o r 15LS Mtron International Business Locations
Secured 10 overseas bases
including China, Brazil, USA, and Vietnam
LS MQ, LS EQ
LS MW
1
POLAND
Branch 7
LS EV
Hanoi
Branch
Subsidiaries
Branches
Growth of international subsidiaries and foothold
2020
2008
3 10
16 C h a r g e t h e , W o r l dLS TA
Atlanta
Branch
ANYANG
LS MB
Sao Paulo
JEONJU Branch
Nongaon, Jeonju
Casco, Jeongeup
LS TOWER, Hi-Tech Center Jeonju Plant, Engine Plant
Head office, Electronic Components, Tractors, Injection Molding Systems
Ultracapacitors, R&D Center, Sales Track Shoes, Tractor Engine
L S U l t r a c a p a c i t o r 17LS ULTRACAPACITOR
+82-31-8045-9598
jsp@lsmtron.com
LS Mtron Hi-tech center, 39, 116beon-gil, LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, 14118, Korea
2020
LS Mtron, Ltd. All right reserved September. 2020You can also read
