eLOCKSTANDARD
#cargosecurity
#eseals

         Protection – Control – Identification – Tracking – RFID Solutions
                                                                             3052 B
ELOCKSTANDARD #cargosecurity #eseals - Protection - Control - Identification - Tracking - RFID Solutions - LeghornGroup
e-LOCK STANDARD                                     the basic electronic lock of
                                                          LeghornGroup

e-LOCK       STANDARD        announces        the
unauthorized opening of the truck / container by
generating a random number, which must be the
same before and after the delivery of the cargo
                                                      Prevents internal theft and fraud along the
                                                      entire supply chain
.
e-LOCK STANDARD is the entry-level product
of the reusable electronic locks family
manufactured by LeghornGroup, with basic
features at a very competitive price.

                                                      As soon as the seal is closed, it automatically
                                                      generates a unique number that can be
                                                      transferred to the cargo documentation

                                                      Simple to use, stand-alone, battery-powered
                                                      unit
ELOCKSTANDARD #cargosecurity #eseals - Protection - Control - Identification - Tracking - RFID Solutions - LeghornGroup
e-LOCK STANDARD

                  e-LOCK STANDARD allows detection of entry
                  throu the use of a randomised serial number.

                  Successfully on the market since 2008,
                  e-LOCK STANDARD has the following
                  recently improvements as for environmental
                  resistance and usability:
                  ▪   IP66 waterproof case
                  ▪ sealing pin made of stainless steel (AISI
                    316) able to withstand a harsh environment
                  ▪ battery replacement set-up
                  ▪ 30% reduction of the device weight
                    (completely plastic case - from 840 gr to
                    590 gr)

                      When locking the seal, it automatically
                      generates a unique random number that
                      can be entered in the freight documents.

                      If the e-LOCK STANDARD displays the
                      same number on arrival, it is certain the
                      cargo doors, trolleys or container have not
                      been opened in transit.

                      A new unique number is generated each
                      time the transport has to stop for
                      additional loading or offloading.
ELOCKSTANDARD #cargosecurity #eseals - Protection - Control - Identification - Tracking - RFID Solutions - LeghornGroup
How does e-LOCK STANDARD work?
  E-LOCK STANDARD works in a very simple way:

  ▪ Each time the pin is pulled out of the plug a random number is generated by the e-LOCK,
    which is shown on the display.
  ▪ By pushing the front button, the previously generated number is recalled on the display.

              ▪ Rugged housing completely protected from water, dust, salt, dirt and oil. It can
                withstand severe temperature ranges.
              ▪ Easy to attach to the back of a truck either by screws or magnets, by using a special
                metal plate.
              ▪ Easy to use and requires no maintenance
              ▪ Long battery lifetime (5000 sealing activities). The battery can be replaced by the
                user, making the e–LOCK STANDARD a very cost effective solution to prevent
                goods losses along the supply chain, almost maintenance-free.
ELOCKSTANDARD #cargosecurity #eseals - Protection - Control - Identification - Tracking - RFID Solutions - LeghornGroup
Technical specifications
     ▪   Dimension:                              106x156x38 mm
     ▪   Weight:                                 590 gr
     ▪   Fixing:                                 4 M6 screws

     ▪   Actuator:                               Mechanical life 1.000.000 cycle
     ▪   Operative temperature:                  -20° C + 50° C
     ▪   Storing temperature:                    -25° C + 80° C

     ▪   Battery:                                Lithium Long life non rechargeable
     ▪   Waterproof:                             IP 66 equivalent
     ▪   Sealing:                                PVC

     ▪   Case Material:                          Shock-resistant Polycarbonate and Polypropylene
     ▪   Vibration:                              Vibration resistant
     ▪   Display:                                LED 5 Digit - Red - night readable

     ▪   Cable pin:                              Inox AISI 316
     ▪   Lock plug:                              Plug with spring lock
     ▪   Security:                               May be locked with other kind of security seal
     ▪   Cable                                   TIR Cable in PVC coated steel cable

              Key Features

             ▪ Robust and easy to use device – No maintenance

             ▪ Long-lasting battery

             ▪ Bright 5 digit LED display illuminates for easy reading, even at night

             ▪ A spring lock holds the plug in place for fast and easy access

             ▪ Sealing pin has a 4mm hole, capable of insertion of a pull-tight seal or cable seal
               for additional security.
ELOCKSTANDARD #cargosecurity #eseals - Protection - Control - Identification - Tracking - RFID Solutions - LeghornGroup
Field of action of LeghornGroup

     PROTECTION: we can protect your              CONTROL: we ensure goods and people
     goods and assets with security seals and     can be monitored using security products
     various products for tamper protection.      and integrated complete hardware and
     The company can create bespoke,              software solutions that allow the operator
     technical solutions to meet client’s         to monitor and intervene in real time,
     requirements.                                even remotely.

     IDENTIFICATION: LeghornGroup’s              TRACKING: LeghornGroup’s real time
     understanding of authentication along       GPS tracking devices allow users to
     with their innovative technical products    monitor location, status and movements
     and solutions allow users to uniquely and   of vehicles and people.
     securely identify, goods, vehicles,
     containers, animals and people.
