SAVE GENERATE STORE UTILISE Effective photovoltaic service for top performance and reliable returns. Complete services and solutions from a single source. www.energy.gildemeister.com
GILDEMEISTER ENERGY SOLUTIONS IS PART OF THE DMG MORI GROUP
Global leaders in development
and service.
The merger of the German GILDEMEISTER Group and the
Japanese Mori Seiki Group in 2013 resulted in a leading global
manufacturer of machine tools and CNC turning and milling
machines.
GILDEMEISTER energy solutions has been
a wholly owned subsidiary of DMG MORI AG, machine tools 54 %
a public limited company since 2007.
DMG MORI AG
• 2
2 production facilities
worldwide
ore than 7,000
• M
employees
• 1
65 national and
international sales
and service sites
Order volume of
> 2.3 billion
EUR
per annum*
46 % industrial services
LifeCycle Services Energy Solutions
*DMG MORI Aktiengesellschaft (financial year 2015)
More than
THE GLOBAL NETWORK OF GILDEMEISTER ENERGY SOLUTIONS
8,000
At home where installations
worldwide
our customers are.
The sun always shines in one of our offices. An international
network of branches and sales partners forms the basis of our
worldwide sales and services.
Countries with
installations from
GILDEMEISTER
energy solutions
GILDEMEISTER energy solutions GmbH GILDEMEISTER energy services GILDEMEISTER energy services
Germany | Würzburg Iberica SLU Spain I Barcelona Italia s.r.l. Italy | Lecce
SUCCESSFUL PARTNERSHIP Fast and flexible for more satisfaction. As a globally operating company, we can offer our customers top-quality service on-site. Our services focus on satisfied customers. Our comprehensive products and services guarantee the best-possible performance for your photovoltaic systems. With our tailor-made service modules, you benefit from services that are a perfect fit with your requirements.
SATISFIED CUSTOMERS WORLDWIDE
“GILDEMEISTER energy solutions is currently providing O&M services for a number of PV plants Vector
Cuatro manages throughout Spain and Italy totaling ca. 50MW. We are very happy to declare that the
performance as O&M contractor is satisfactory, having always achieved the guaranteed metrics under the
O&M Contracts. Special mention is worth be done to the Spanish branch, which has not only achieved but in
general terms exceeded the expectations, especially with regards to responsiveness and client oriented attitude.”
Matías Gallego, Technical Director, Vector Cuatro Group
“Since 2011 GILDEMEISTER energy solutions has supervised our photovoltaic plants in Spain. From
the beginning, we valued GILDEMEISTER energy solutions performance, particularly their proactive,
reliable and quick response to technical issues. We consider GILDEMEISTER as an excellent service
provider and strongly recommend them.”
Stephan Thoenissen, Investment Reporting Group, ERGO Versicherungsgruppe AG
“Goldbeck Solar enjoys working with GILDEMEISTER energy solutions as local O&M partner.
Only with a strong partner we can deliver smooth operation of the plants at competitive cost. With
GILDEMEISTER’s expertise we can rely on a fast fault clearance and minimize downtime.”
Oliver Janisch, Head of O&M, GOLDBECK Solar GmbH
“GILDEMEISTER energy services impressed us in the tender for the operations management of
our PV systems with quick and clear statements and competitive pricing. The partnership is very
professional and pleasant.“
Rainer Isenrich, CEO/CFO, Edisun Power Europe AG
“CHORUS Clean Energy AG has been cooperating successfully with GILDEMEISTER energy services Italia
since 2009. GILDEMEISTER attends to our solar parks in the region of Apulia, in the south of Italy, and thereby
takes care of service and maintenance responsibilities for our systems, which have a total capacity of about
twelve megawatts. We intend to continue our working relationship with GILDEMEISTER in the coming years
and are very satisfied with their service offer and the implementation thereof.“
Afroviti Capo, Operations Service, CHORUS Clean Energy AG
RANGE OF SERVICES Individual service for every photovoltaic system. We will gladly prepare a tailor-made offer for you from our comprehensive range of services. Irrespective of whether it is a fixed installation, a tracking system or a rooftop system.
Service
around the clock
24 / 7 / 365
Service hotline:
08000 365 7 24
YOUR PARTNER: GILDEMEISTER ENERGY SOLUTIONS
• E xperience gained from more than 8,000 • Top bankability
installations worldwide • Guaranteed security of the data link thanks to VPN
• P roven significant yield improvement after takeover encryption
of servicing for third-party parks • Certified partner of various inverter manufacturers
• Reaction times to fault detection < 15 minutes • In-house fitters and technicians
• Fault clearance after failure (if applicable) < 12 h
FROM CONSULTATION TO COMPREHENSIVE SERVICE
Service is only perfect if everything
runs perfectly.
With our service and maintenance offers, we ensure maximum energy
yield and the best operational availability of your photovoltaic system in
the long term. Local service technicians are on standby for our customers
in order to be on site by no later than 3 p.m. on the next working day in
case of a production-related fault.
WE ARE ALWAYS AVAILABLE FOR YOU!
Our experienced and highly qualified
GILDEMEISTER energy solutions employees
are at your disposal 24 hours a day, seven
days a week, via our service hotline.
Service hotline: 08000 365 7 24
OUR SERVICES
SYSTEM
COMMERCIAL OPERATIONS MANAGEMENT
MONITORING
• R
emote monitoring of the PV system 24 / 7 / 365 Accounting and financial bookkeeping
• Daily evaluation of systems data and • B
illing and auditing
performance • E
xecution of payment transactions
• Fault detection < 15 minutes • H
andling of all incidental booking activities
• Fault analysis and initiation of measures (financial bookkeeping)
(ticket system) • A
dvance VAT returns
• Active information for plant operators about faults
• Creation of reports/reporting, including solar Annual financial statements and tax returns
radiation data, energy production, fault logs • P reparation of the annual financial statements
• Individually selectable reporting intervals • P reparation of annual tax returns
(annually, quarterly, monthly, weekly) – utilisation • C hecking the relevant assessments
of customer-specific report templates on request • I nvolvement in the external auditing of
• Optional monitoring of feed-in and financial administration
consumption meters (depending on the
technical specifications of the meters) Management support
• Y
ield and cost optimisation of projects
(direct marketing, insurance, financing, etc.)
• C
oordination of result allocation, building up of
reserves, withdrawal of liquid funds
• O
rganisation and holding of shareholder meetings
TECHNICAL MANAGEMENT
Business evaluations / management accounting
• P reparation of a budget and liquidity plan
• O rganising maintenance work, roof renovation if • D ividend payment planning
required, safety installations on the roof, recurring • Individual evaluations
inspections - Monthly business evaluations
• Organising and coordinating the service - Monthly profit-and-loss accounts
assignments of various service providers - Monthly target-performance comparisons
• Ongoing checking of component warranty periods against budget
(inverters, modules, etc.)
Financing and cash management / bank support
• M anagement of bank accounts in line
with strict security requirements
• I nvestment of liquidity reserves
• D ebt capital management
MODULE CLEANING
• M onitoring of compliance with financing
requirements imposed by the bank
• C
leaning of the modules in a gentle, • S upervision of share transfers
environmentally friendly way • P rovision of commercial documentation
• Removal of all mineral and organic soiling and investment reports
(e.g. dust, deposits, fats, pollen, lichens and
mosses, insects, bird droppings, leaves Support for shareholders /
and pine needles) stakeholders and project players
• Compliance with manufacturers‘ specifications • R elations with shareholders / stakeholders
• Evaluation of the degree of soiling and consultation and project players (energy suppliers, landlords,
about requirements official bodies, etc.)
• Sensible scheduling according to local
conditions (harvesting dust, pollen drift,
construction dust, etc.)
MAINTENANCE / INSPECTION (PLANNED / SCHEDULED OPERATIONS)
Proactive maintenance Recurring inspection of the system in
accordance with DGUV Regulation 3
Preventive maintenance (statutory accident insurance provisions)
• Annual inspection of the system • I nspection of the electrical systems and on-site equipment
(different intervals can be chosen on request)
• Precise reporting about the condition of the Maintenance of the transformer station -
system, with fault report if applicable Medium-voltage switchgears
• Evaluation of the condition of the system and • I nspection of the general condition of the transformer
recommended courses of action, if applicable and transformer building (screwed connections,
• Support and module attachment terminals, fuses)
• Checking the construction (screwed connections, corrosion, • F unctional test of the components (gas pressure, fluid level,
weather damage such as due to storms, snow and ice) power system protection, power supply voltage, UPS)
• PV modules • C leaning of SF6 medium-voltage switchgears
- Measurement of the strings • Earth measurements
- Checking the module connectors • Thermographic tests
- hecking the degree of soiling
- Fit and tightness of module clamps E-CHECK measurements of the low-voltage system
- Checking the condition of the cables • V
isual inspection pursuant to IEC 60364
- Checking that module connectors fit correctly • C
hecking of insulation resistance, continuity of
• Inverters protective earth conductors and equipotential bonding,
- Checking the degree of soiling earth resistance, loop impedance, line impedance,
- Checking for moisture and possible damage RCD inspection, phase sequence
- Checking the connectors and screw connections (DC/AC)
- Checking of the overvoltage protection systems
• Cabling
- Checking for corrosion and weathering
- Checking for proper laying and fixing
- Inspection for damage caused by external influences
such as rodents, birds, wind, ice and snow
REPAIR / CORRECTIVE MAINTENANCE
SYSTEM OPTIMISATION AND REFITTING
(UNPLANNED)
• I nspection and evaluation of historical • R epair of failures and damage within two working
system performance days, depending on availability of material
• Inventory of the condition of the system • I mmediate preparation of a detailed
and its components damage report
• Expert opinion by in-house certified TÜV expert • S ubmission of recommended courses of action
• Submission of recommended courses of action
• Cost breakdown for yield optimisation of the system
• Implementation of optimisation measures
• Checking the effectiveness of third-party MAINTENANCE OF PARKS AND
refitting measures SECURITY FENCES
• M
owing of the meadow area
• P
runing of shrubs and trees
• C
hecking the condition of the fence and repairing
any damageSYSTEM TESTING, ASSESSMENT,
THERMOGRAPHY
ANALYSIS, REVISION
• I n-house certified TÜV appraisers / experts in • T
hermographic inspection of the PV system on site
photovoltaic systems (TÜV) are familiar during the operational phase
with acknowledged technical regulations and • T
esting carried out by specialist staff with
can draw up sound expert opinions on Level 1 certification from ITC Stockholm
systems for photovoltaic energy generation
Targeted detection of potential defects
• Hotspots
Knowledge / skills • Cell breakage
• Building legislation, standards, • Delamination
technical regulations • D efective bypass diodes
• Cost and feasibility studies • Short circuits
• Identification and evaluation of faults • F aulty soldered connections
in photovoltaic systems • Electronic parts
• Expert services • Inverter transformers
• E quipment connection boxes
Assessment services • P rofessional software-based analysis of
• Compliance with DIN standards, VDE regulations, thermograms
installation instructions, structural properties and
corrosion of metals Precise reporting about the condition
• Inspection of the PV system before the warranty of the PV modules, including
period elapses or if there is a suspicion of impaired • E valuation of the measurement results
performance • C lassification of anomalies
• Detection of yield losses caused by faulty modules • P hotographic documentation of thermal anomalies
• Inspection of all essential components for proper • Recommended courses of action
and defect-free installation (rooftops / open areas)
• Checking whether individual PV modules produce
the guaranteed output
FLEXIBLE PAYMENT OPTIONS
• L
inking the payment to the annual yield in kWh* in
PID EFFECT
the event of a full-service maintenance agreement
• C
onventional upfront payment (yearly, half-yearly
• C
hecking and assessment of modules for or quarterly)
the PID effect
• Detailed reporting and submission of * only for systems > 1 MWp and for a contract duration
recommended courses of action of more than 5 years
• Carrying out of repair work and preventive
measures
SPARE PARTS MANAGEMENT
Tailor our
• S afe storage of necessary components
• Insurance of stored spare parts
service to your
• Back-up stocks with the relevant needs
manufacturer on request
• Ongoing monitoring of stock levels
• Active information in case of critical stock levelsLONG-TERM PARTNERSHIPS
Together, we are strong.
We cooperate with renowned manufacturers worldwide in order to be able
to offer optimum maintenance for your systems.
Making Quality Visible
global player
–
global
resourcingPROFESSIONAL SERVICE FOR MAXIMUM PROFITABILITY
A complete solar service that
makes all the difference.
We do everything to achieve maximum profitability for your photovoltaic installation. This is a promise we
already keep with a comprehensive aftersales service at numerous photovoltaic installations. Worldwide.
Day after day. DMG MORI AG has been renowned for technical expertise, reliability and efficiency for more
than 140 years. Focused services provided by our specialists ensure smooth system operation for maximum
energy yield and the best-possible availability of the systems.
By the way: GILDEMEISTER energy solutions is also a specialist in turnkey project solutions – from project and
systems management through to construction and operation. If you are looking for a reliable EPC partner with a
first-class product portfolio and international project experience, you came to the right place!
CONTACT US
We will gladly provide consultation and prepare an GILDEMEISTER energy solutions GmbH
individual offer for you. Carl-Zeiss-Str. 4
97076 Würzburg | Germany
Contact persons: Ralf Reichert, Markus Kröhl Tel +49 (0) 931 250 64-120
energysolutions@gildemeister.com Fax +49 (0) 931 250 64-102
www.energy.gildemeister.comREFERENCE PROJECTS Perfect solutions – satisfied customers. Hörselgau | Germany Langeln | Germany Kaufbeuren | Germany Kairo | Egypt Zveretice | Czech Republic Creswell | UK
Carlino | Italy Ginosa | Italy Ploiești | Romania Murcia | Spain La Molineta | Spain Las Capitanas | Spain
Energy-efficient complete solutions.
Energy saving
GILDEMEISTER energy solutions has an essential and extensive
awareness of energy, focusing on the intelligent generation, storage
and utilisation of energy.
The cornerstone of a comprehensive energy solution is the lowering
of energy costs and consumption through an energy analysis and the
implementation of a GILDEMEISTER energy monitor.
Energy efficiency in industry
Energy generation
Simply take control of power supply – with the intelligent, renewable
power-generation systems of GILDEMEISTER energy solutions.
Whether it is a fixed installation, a tracking system or a rooftop system:
with our systems, you utilise the power of the sun in its most efficient form.
PV installation, Spain
BRO D6975 / 0 616UK
Energy storage
CellCube: this vanadium-based energy storage system with a long service
life offers an uninterrupted supply of power. It is available with power
ratings from 10 to 200 kW and a scalable capacity up into the MWh range.
In this way, base load coverage, power peak limiting and the safeguarding
of sensitive areas can be guaranteed at all times.
Energy solutions park, Bielefeld, Germany
Energy utilisation
Intelligent products and technologies for modern industry:
• E-mobility solutions • Industrial solutions • Backup solutions
• Off-grid solutions • Tele solutions • Power solutions
E-mobility solution at DMG MORI Global Headquarters Winterthur,
Switzerland
Our energy experts will gladly compile a concrete plan of measures together with you for the sustainable lowering of your energy
costs. Give us a call: +49 (0) 931 250 64 -120
GILDEMEISTER energy solutions GmbH All information here!
Carl-Zeiss-Str. 4, 97076 Würzburg, Germany T +49 (0) 931 250 64 -120, F +49 (0) 931 250 64 -102
GILDEMEISTER energy efficiency GmbH
Riedwiesenstraße 19, 71229 Leonberg, Germany If your mobile phone has QR software
GILDEMEISTER energy storage GmbH installed, you can go directly to
Industriezentrum NÖ Süd, Straße 3, Objekt M36, 2355 Wiener Neudorf, Austria www.energy.gildemeister.comYou can also read
