dCache: An Overview
Paul Millar
on behalf of the dCache team
Nordic Data Management Workshop
Oslo, Norway; 2019-02-27
https://indico.cern.ch/event/779913/
eXtreme DataCloud is co-funded by the Horizon2020
Framework Program – Grant Agreement 777367
Copyright © Members of the XDC Collaboration, 2017-2020
Scientific data challenges
●
Volume
●
Fast ingest
●
Chaotic Access
●
Sharing data
●
Access Control
●
Persistence & long-term
archival
●
Immutability
dCache: An Overview | | 2019-02-27 | 2
Data management
& workflow control
(Rucio, Kafka, SSE)
High Speed
Data Ingest
Fast Analysis
Interactive analysis
NFS 4.1/pNFS
& Sharing
Wide Area Transfers
(Globus Online, FTS)
by GridFTP, HTTP
dCache: An Overview | | 2019-02-27 | 3
●
HERA
●
Tevatron
●
WLCG
●
Belle II
●
LOFAR
●
CTA
●
IceCUBE
●
EU-XFEL
●
Petra3
●
DUNE
●
And many more ...
dCache: An Overview | | 2019-02-27 | 4
Flexibility that works …
●
Supports many authentication schemes: username+password,
X.509, Kerberos and OpenID-Connect:
●
Integrates with existing infrastructure + pluggable for flexibility,
●
Users have same rights, irrespective of how they authenticate.
●
Supports delegated authorisation, using Macaroons.
●
Multiple protocols: (Grid)FTP, HTTP/WebDAV, SRM, xrootd, NFS
v4.1/pNFS and dcap.
●
Using different protocols, users will see the same data.
dCache: An Overview | | 2019-02-27 | 5
dCache innovations: Storage Events
Storage events: the problems
Upload a file Stage files from tape
OK Request queued
Are these files on disk?
Delete a file no, no, no, …
OK
Are these files on disk?
no, no, no, …
…
Are these files on disk?
no, YES, no, …
Catalogue: Rucio/LFC/…
dCache: An Overview | | 2019-02-27 | 7
9000 stats per second!
dCache: An Overview | | 2019-02-27 | 8
dCache: An Overview | | 2019-02-27 | 9
An new approach: storage events
Subscribe to events
OK
Something happened #1
Something happened #2
Something happened #3
dCache: An Overview | | 2019-02-27 | 10New solutions to old problems:
Subscribe … ●
User- and internally triggered
Upload
OK events:
OK File uploaded ●
Data uploaded
●
Data deleted/renamed/moved
Delete ●
Tape flush/stage operations
File deleted
OK ●
Uses: update catalogue, metadata
Rucio
extraction, data normalisation,
build derived data, …
Stage files
Request queued
●
Two event systems:
Subscribe … ●
Site integration (Kafka)
OK
●
Per user events (SSE/inotify)
File #16 on disk
(DEMO :-)
dCache: An Overview | | 2019-02-27 | 11dCache innovations: Distributed storage & Data Lakes
Data Lakes: distributed resources
●
dCache has over a decade of production use as a data lake:
●
NDGF is a distributed dCache, spread over five countries.
●
AGLT2 is a distributed dCache, spread over two campuses.
●
dCache can already provide protocol-based QoS; e.g., cache data for
NFS access, read remotely for HTTP/GridFTP.
●
Currently building new testbed to demonstrate existing solutions and
improve upon them:
Hamburg → Zeuthen (RTT: ~5 ms); Hamburg → Moscow (RTT: ~70 ms)
●
Adding ability to provide cached data when detached:
A “satellite” can offer data if disconnected from the rest of dCache.
dCache: An Overview | | 2019-02-27 | 13Data Lakes: cloud bursting
●
dCache stores data in either a local filesystem or as objects within a
CEPH cluster.
●
Two new developments:
●
Storing data within an S3 endpoint
●
Dynamic pools: just start a dCache pool and that capacity becomes usable.
●
Together, support the cloud bursting use-case:
●
As cloud capacity “comes online” either due to load (cloud burst) or due to
resources being cheap (Amazon grants) then start a dCache pool
●
Jobs can run “in the cloud” with dCache taking care of any data movement.
dCache: An Overview | | 2019-02-27 | 14dCache innovations: Delegated Authorisation with Macaroons
Macaroons: delegated authorisation
Photo by Alan Cleaver (CC-BY)
dCache: An Overview | | 2019-02-27 | 16Example use: community portals / BOINC
User
Database
1. Request data
2. Request a macaroon
GET
307
GET 3. Request data directly from dCache
dCache
dCache: An Overview | | 2019-02-27 | 17Example use: ad-hoc sharing
1. Request a macaroon
2. Send to colleague
(e.g. via email)
GET/PUT/DELETE
dCache
3. Use macaroon
dCache: An Overview | | 2019-02-27 | 18dCache Workshop: 2019-05-21 to 2019-05-22
●
Located in Madrid, Spain.
●
Learn more about latest
developments in dCache
●
Opportunity to discuss issues directly
with dCache developers
●
Share stories with dCache admins
●
Help shape the future direction of
dCache.
https://indico.desy.de/indico/event/22170/
dCache: An Overview | | 2019-02-27 | 19The take-home message
●
dCache is advance storage software for data-intensive
science.
●
dCache:
●
has decades of production use throughout the world,
●
provides scalable resources, used by many scientific disciplines,
●
offers innovative solutions that help drive the next generation
of scientific discovery.
dCache: An Overview | | 2019-02-27 | 20Backup slides
dCache 101: Motivation
●
Data never fits into a single server
●
Multiple servers
●
Off-load to tape
●
Growing number of client hosts
●
Mainframe vs Linux cluster
●
Control over hardware/OS selection
●
Better tender offers
●
Use and enhance local expertise
dCache: An Overview | | 2019-02-27 | 22dCache 101: Design
●
Single-rooted namespace, distributed data
●
Client talks to namespace for metadata operations only
●
Bandwidth and performance grow with number of data
servers
●
Standard clients (OS native or experiment)
●
Some data can be offloaded to tape
dCache: An Overview | | 2019-02-27 | 23What are macaroons good for?
3. Add caveats
GET 2. Request a macaroon
307
GET
4. Request data directly from dCache
Processing data without user credentials / BOINCWhat are macaroons good for?
5. GET with macaroon
4. COPY with
2. Request a
embedded macaroon
macaroon
1. Request copy
FTS 3. Add caveats
HTTP 3rd party copiesWhat are macaroons good for?
2. Request a macaroon
3. Add caveats
1. Request access Rucio
to data
4. Access data
Enforcing catalogue permissionsComparison: it’s what industry is doing…
Comparison: it’s what Open-Source is doing…
dCache Storage Events: Kafka
created
staged
Log
billing
billing Log
billing
billing
created
stageddCache Server-Sent Events (SSE)
●
Based on HTTP v1.1
●
HTML 5 standard
Support for many languages and web-browsers
●
Initially adding support for inotify events
(it’s how Linux does namespace notification)
●
Plan to add:
●
Locality change notification: flush, stage, …
●
Transfer-related events
●
QoS changesCheat sheet: Kafka vs SSE
SSE
Standard … Component Protocol
What events does it see? dCache internal events Controlled
Main benefit Easy integration Built-in security
“Catch-up” storage Memory & disk Memory-only
(currently)
Target audience Site-level integration Events for usersEOSC-Pilot demonstrator: EU-XFEL data ingest
new RAW data
store derived file create
derived
data
extract
metadata metadata
catalog
update catalogRucio demonstrator: automated replication with SSE
New data
Upload SSE
Rucio
Third-party copyFuture directions
●
Complete SSE inotify support in dCache.
●
Add additional events, based on initial feedback.
●
Further explore automated data workflow (EU-XFEL
usecase).
●
Work with Rucio team to explore SSE integration.
●
Work with dCache sites to deploy store events in
production.You can also read
