INT
Caravans 2022
Technical Information
Dethleffs Plus Factors – Explanation of symbols
In the Dethleffs caravans, there are a lot of smart ideas and standard features for more safety and comfort. Here we present the
most important ones with the corresponding symbols which can be found on the pages of the vehicle. More detailed information
can be found at: www.dethleffs.com/plus-factors.
Family benefits Added comfort Added safety
Happy family: Layouts with bunk Inviting: 70 cm wide XXL entrance Vehicle roof made of robust
beds - ideal for families. Up to door GRP – protects from unusual
three bunk beds available as an weather conditions
option.
Practical refrigerator with SleepWell: Fixed beds with 7-zone Roof, front and rear made of
large volume and separate freezer mattresses with ergonomic robust GRP
compartment (details see wooden slatted bed frames
technical data)
More room: Fold-away lower bunk Better safe than sorry: Benefit
bed for more storage or greater from Safety Packages for more
playground (dep. on model) safety on the road (option)
More legroom: One-leg telescopic Safety on the road: Brand chassis
table with easy lowering function from safety experts
for converting the lounge to bed
Safety clutch: Stabilises rolling
ACS
and pitching movements
Added equipment
Agile travelling - with caravans Safety on the road: Thanks to the
that go up to 100 km/h outstanding deceleration values
and automated re-adjustment
Winter expert! Winter-proof
caravans thanks to optional
Winter Comfort Packages (option)
For a healthy room climate:
Optimum ventilation of the
overhead lockers avoids
condensation
Caravans 2022
C’JOY C’GO C’GO UP AERO CAMPER®
Single-axle Single-axle Single-axle Single-axle Single-axle
max. max. max. max. max. max. max. max. max. max. max. max. max. max.
5 7 6 6 6 7 6 6 6 6 6 6 6 6
Bunk bed
layouts
Being a friend of 8m
the family we focus
on a wide range of 6m
bunk bed layouts 5m
for children and
big families. The
Conversion length
maximum number
of sleeping berths
includes the lounge
convert, the three
bunk beds‘ option 410 LK 480 QLK 495 QSK 565 FMK 465 KR 525 KR 470 FSK 490 QSK 500 QSK 500 QSK 530 FSK 540 QMK 550 ESK 560 FMK
and some optional
extras. Width 2,12 m 2,12 m 2,3 m 2,5 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,5 m 2,3 m 2,5 m
max. max. max. max. max. max. max. max.
3 3 3 4 4 3 4 4
8m
6m
Double bed
5m
layouts
A large bed for two
Conversion length
persons: For those
who share a double
bed at home,
will be happy to
have the same 420 QSH 480 FSH 415 QL 475 FR 495 FR 410 QS 470 FR 470 FR
conditions when
travelling. Width 2,12 m 2,12 m 2,2 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m
max. max. max. max. max. max. max. max. max.
3 3 3 4 4 3 3 4 4
8m
6m
Single beds
5m
layouts
Travel together,
Conversion length
spend time
together and sleep
in separate beds.
Our single beds‘
layouts are perfect 460 LE 475 EL 470 EL 510 ER 520 ER 460 EL 470 ER 510 LE 510 ER
for your individual
requirements. Width 2,12 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 m 2,3 mCAMPER® NOMAD BEDUIN SCANDINAVIA
Tandem-axle Single-axle Tandem-axle Single-axle Tandem-axle
max. max. max. max. max. max. max. max.
6 8 6 8 5 6 7 5
650 FMK 730 FKR 560 FMK 730 FKR 540 QMK 590 RK 650 RFK 740 BFK
2,5 m 2,5 m 2,5 m 2,5 m 2,5 m 2,5 m 2,5 m 2,5 m
max. max. max. max. max. max. max.
4 3 4 4 4 4 4
470 FR 490 BLF 530 DR 650 RQT 760 DR 550 RD 690 BQT
2,3 m 2,3 m 2,3 m 2,5 m 2,5 m 2,3 m 2,5 m
max. max. max. max. max. max. max. max. max. max.
3 3 4 4 3 4 3 3 4 3
460 EL 490 EST 510 ER 510 LE 520 ELT 560 RET 550 BET 550 SE 650 RE 670 BET
2,3 m 2,3 m 2,3 m 2,3 m 2,5 m 2,5 m 2,3 m 2,3 m 2,5 m 2,5 mINDEX CARAVANS 2022
c'joy c'joy ........................................................................................................................... 7
c`go & c´go up! c´go & c´go up! .........................................................................................................13
Aero Aero......................................................................................................................... 21
Camper® Camper® ................................................................................................................. 28
Nomad Nomad..................................................................................................................... 37
Beduin Scandinavia Beduin Scandinavia................................................................................................. 47
Technical information ............................................................................................. 55c'joy
Less is more fun! Technical info*
Technically permissible total mass 1100 - 1200 kg
Less weight, lower price, pure caravan joy! The c'joy has everything
Overall length, approx. 617 - 716 cm
you need for the life of freedom. Thanks to its compact size and
low weight, it is also suitable for smaller cars. Depending on the Overall width, approx. 212 cm
towing vehicle, it can also be driven with a Class B driver's licence.
Overall height, approx. 261 cm
In spite of its compact size, it has lots of space for two or more
passengers; all at an affordable price. Have a joyful journey! * Maximum values partly not possible for all models or only in connection with
certain options.
Upholstery Plus factors
+ The perfect caravan for beginners: great value and it has
everything you need
+ No fear of narrow passages: one of the narrowest
caravans in its class with a 2.12 m width
+ Clipper upholstery + Portobello + Lightweight: It can be towed with a small car with
standard Class B driver's licence (depending on towing
upholstery *
vehicle)
+ Protects you from bad weather: roof, front and rear
made of robust GRP
Wood décor + You don't have to make compromises: you can bring as
much as you need as there is lots of storage space and
high load capacity
+ Sambesi Oak wood décor
*optionally available
7c'joy
Technical info
c'joy 410 LK 420 QSH 460 LE 480 FSH 480 QLK
Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1100 kg chassis, 1100 kg chassis, 1200 kg chassis, 1200 kg chassis, 1200 kg
Overall length, approx. cm 624 617 674 707 716
Overall width, approx. cm 212 212 212 212 212
Overall height, approx. cm 261 261 261 261 261
Headroom in living area, approx. cm 198 198 198 198 198
Insulation floor / side walls / roof mm 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28
Tire size 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR
Bed dimension: Front bed, L x W, approx. cm 190 x 140 - 115 195 x 150 190 x 100 - 90 200 x 160 190 x 150
Bed dimension: Central / middle bed, L X W, approx. cm - 170 x 90 - 80 - 170 x 90 190 x 120
190 x 65 / 190 x 190 x 60 / 190 x
200 x 80 / 195 x
70 / 2x 190 x 70 70 / 2x 190 x 60
Bed dimension: Rear bed, L x W, approx. cm - 80 / 200 - 195 x -
/ 190 x 60 / 190 x 70
190
Sleeping berths 4/5 3 3 3 6/7
Unladen weight, approx. kg 841 839 882 942 946
Mass in running order, approx. kg 874 872 915 975 979
Maximum load, approx. kg 226 228 285 225 221
Technically permissible total mass kg 1100 1100 1200 1200 1200
S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW
Heating
Gas Gas Gas Gas Gas
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15) 86 (11) 142 (15) 86 (11)
Water supply incl. boiler (reduced volume) ca. l 12 12 12 12 12
8Standard equipment
420 QSH
480 QLK
480 FSH
460 LE
410 LK
Chassis
Zinc-plated chassis with inertia braking system with reversing automatic
Chassis features
Lightweight zinc-plated corner steadies
High-quality brand-name tyres, designed for a speed of 100 km/h
Single-axle premium steel wheel set 185 R14 C 8 PR, up to 1.600 kg
Exterior features
Glass bottle locker for 2 x 11 kg
Floor of the gas bottle locker made of rot-resistant and robust corrugated aluminium
Front, rear and roof made of robust GRP
Standard window, graphite grey
Two-piece entrance door
Exterior design
Sides in hammer finish, white
Access locker doors
Access locker door rear right 560x1150 mm
Interior design
Sambesi Oak wood décor
Clipper upholstery
Textile equipment
7-zones cold foam mattress single bed right standard
7-zones cold foam mattress single bed left standard
Cold foam double bed mattress
Furniture layouts
AirPlus - perfect air circulation in the interior and rear ventilation of the overhead lockers and sideboards
Seating lounge converts to bed
Special slatted frame with flexible natural rubber holders, opening for optimal use of storage compartments under the beds
Bunk beds with safety net and ladder
Bunk bed with 2 sleeping berths, foldable
Kitchen
Large fridge with 142 l volume and 15 l freezer
Practical 3-flames cooker with manual ignition
Bathroom
Trendy washbasin made of stainless steel
Shower tray
Skylight with mosquito net
Heating
Gas heating S 3004 with automatic ignition
Electrical installation
Awning light 12V
12 V power supply throughout vehicle
CEE external output socket for 230V on-board electrics
Compact power distribution unit with 230V safety device and 12V fuse box in wardrobe incl. powerful 340W transformer
Water supply
Fresh water tank 20 l
Electric water supply
Optional extra Not possible Standard Mandatory
9PACKAGES C'JOY
Dynamic Package
Package Dynamic Package (9241) Dynamic Package (9242)
(12359)
ACS stabiliser x x x
Octagon shock absorber x x x
Spare wheel carrier in gas locker x x x
Fresh water tank 44 l x x x
Mobile 22 l waste water tank x x x
Access locker door front right 1000x420 mm x
Access locker door rear right 1000x420 mm x
Access locker door front right 750x300 mm x
Package Autonomy Package I (10011) Autonomy Package II (10012)
Battery (95 Ah) x x
Battery charger x x
Central 12V main switch x x
Voltage display x x
Fan 12V for S 3004 x
Touring Package c'joy (9243)
Hot-water supply
Hot-air system
Skylight, 700 x 500 mm
Flyscreen door
10Included in Additional Code
Optional extras package weight
420 QSH
480 QLK
480 FSH
460 LE
410 LK
Chassis
Weight upgrade to 1.200 kg 0 134
Weight upgrade to 1.300 kg 0 135
Weight upgrade to 1.360 kg (without chassis change) 0 9619
Weight upgrade to 1.360 kg (with chassis change) 0 9619
Weight upgrade to 1.500 kg 24 136
Chassis features
ATC Trailer Control 4 748
Corner steadies incl. large-area support feet 1 9138
Draw bar cover 3 434
Wheel trims for 14" tyres 2 276
Alloy wheel 185 R14 C LI 102, up to 1.600 kg 0 836
Spare steel wheel 185 R14 C 8 PR, up to 1.600 kg 18 831
1)
Spare steel wheel 185 R14 C 8 PR, up to 1.600 kg 18 831
Spare alloy wheel 185 R14 C LI 102, up to 1.600 kg 17 837
1)
Spare alloy wheel 185 R14 C LI 102, up to 1.600 kg 17 837
Exterior features
Spare wheel carrier in gas locker DP 1 432
Front window 4 982
Kitchen window, sliding (change of window shape) 2 6406
Opening window in bathroom 3 1028
Skylight Mini Heki 5 786
Skylight, 700 x 500 mm TP 8 tba
Flyscreen door TP 2.5 360
Access locker doors
Access locker door front left 1000x420 mm 2 6415
Access locker door front right 1000x420 mm DP 2 6416
Access locker door rear left 1000x420 mm 2 6417
Access locker door rear right 1000x420 mm DP 2 6418
Access locker door front right 750x300 mm DP 2 6420
Interior design
Portobello upholstery 0 9239
Textile equipment
Bed cover for single bed mattresses in upholstery colour 0 6377
Bed cover for double bed mattress in upholstery colour 0 6377
Bed cover for double bed mattress and 2 bunk beds in colour of upholstery 0 6377
Bed cover for double bed mattress and 3 bunk beds in colour of upholstery 0 6377
Furniture layouts
Bunk bed with 3 sleeping berths, not foldable 20 200
Single beds convert to double bed 5 685
Multimedia
Preparation for flat screen TV (antenna cable and TV bracket) 2 678
Multifunctional external connection, 12 V, 220 V, TV and SAT 1 611
Heating
Ultraheat additional heating for S 3004, electric 220 V 2 364
Fan 12V for S 3004 AP 2 177
Hot-air system TP 9.5 142
Air Conditioning
Pre-wiring for A/C 0 172
Electrical installation
Additional lighting through LED spotlights 2 9692
11Included in Additional Code
Optional extras package weight
420 QSH
480 QLK
480 FSH
460 LE
410 LK
USB port for spotlight bar 0 9989
Water supply
Fresh water tank 44 l DP 3 9240
Mobile 22 l waste water tank DP 2.5 367
Hot-water supply TP 15 123
Shower equipment with shower fittings and curtain 5 1097
Gas supply
Gas detection system 0 10058
Packages
2)
Dynamic Package 17.5 9241
2)
Dynamic Package 17.5 9242
2)
Dynamic Package 17.5 12359
Touring Package c'joy 37.5 9243
3)
Autonomy Package I 32 10011
Autonomy Package II 30 10012
Accessories - Highlights (orderable via Dethleffs Original Accessories)
Retrofittable multifunctional rail 0 3269437
Caravan "cellar" 0 3103933
Organiser apron 0 3103940
Floor skirt 0 3103943
Fit cover mono axle 0 3103953
Optional extra Not possible Standard Mandatory
DP Dynamic Package TP Touring Package AP Autonomy Package
12c´go & c´go up!
Caravans to go Technical info*
Technically permissible total mass 1200 - 1600 kg
The c'go will inspire you to pack your luggage and go on tour. It
Overall length, approx. 631 - 803 cm
looks modern and fresh, is available in four trendy upholstery
designs and offers a wide selection of layouts: from the smallest Overall width, approx. 220 - 250 cm
compact one to the spacious family caravan. That makes it an ideal
Overall height, approx. 261 - 271 cm
journey companion and very popular with young couples and small
families. And if you're wondering... this caravan comes with an * Maximum values partly not possible for all models or only in connection with
attractive price. So when are you setting off? certain options.
Upholstery Plus factors
+ Something for everyone: the layouts offer a wide range
for families of all sizes
+ Fresh look: chic, modern interior design and a colourful
choice of upholstery for every taste
+ Grey Orbit + Blue Lagoon + Protects you from bad weather: roof, front and rear
made of robust GRP
upholstery upholstery *
+ Nothing needs to be left at home: you can bring as much
as you need as there is lots of storage space and high
load capacity
+ Lightweight: It can be towed with a small car with
standard Class B driver's licence (depending on towing
vehicle)
+ Green Paradise + Sunshine
upholstery * upholstery *
Wood décor
+ Pearlwhite wood décor
*optionally available
13c´go & c´go up!
Technical info
c´go & c´go up! 415 QL 475 EL 475 FR 495 FR 495 QSK 565 FMK
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1200 kg chassis, 1300 kg chassis, 1300 kg chassis, 1360 kg chassis, 1360 kg chassis, 1600 kg
Overall length, approx. cm 631 676 680 725 714 803
Overall width, approx. cm 220 230 230 230 230 250
Overall height, approx. cm 261 261 261 261 261 261
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28 38 / 28 / 28
Tire size 185 R14C 8PR - 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR
210 x 85 / 185 x
Bed dimension: Front bed, L x W, approx. cm 200 x 135 210 x 145 - 110 200 x 145 - 110 210 x 135 205 x 165 - 130
85 / 200 x 190
Bed dimension: Central / middle bed, L X W,
approx. - - - - 190 x 90 200 x 110
cm
2x 200 x 80 / 2x
2x 210 x 75 / 3x
Bed dimension: Rear bed, L x W, approx. cm 200 x 130 - 100 210 x 105 210 x 150 - 130 210 x 150 - 130 200 x 80 /
210 x 75
200 x 70
Sleeping berths 3 3 4 4 5/6 5/6
Unladen weight, approx. kg 974 - 1066 1137 1146 1357
Mass in running order, approx. kg 1009 - 1101 1172 1181 1392
Maximum load, approx. kg 191 - 199 188 179 208
Technically permissible total mass kg 1200 1300 1300 1360 1360 1600
S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 5004, 6 kW
Heating
Gas Gas Gas Gas Gas Gas
Refrigerator volume incl. freezer, approx. l 90 (9) 90 (9) 90 (9) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 23 23 23 23 23 23
Water supply incl. boiler (reduced volume) ca. l 44 (15) 44 (15) 44 (15) 44 (15) 44 (15) 44 (15)
14c´go & c´go up!
Technical info
c´go & c´go up! 465 KR up! 525 KR up!
Lightweight Lightweight
Standard chassis
chassis, 1500 kg chassis, 1600 kg
Overall length, approx. cm 682 756
Overall width, approx. cm 230 230
Overall height, approx. cm 271 271
Headroom in living area, approx. cm 208 208
Insulation floor / side walls / roof mm 38 / 28 / 28 38 / 28 / 28
Tire size 185 R14C 8PR 185 R14C 8PR
205 x 75 / 200 x
Bed dimension: Front bed, L x W, approx. cm 2x 210 x 95 75 / 175 x 90 -
80
Bed dimension: Central / middle bed, L X W, approx. cm - -
200 x 145 / 210 200 x 145 / 212 x
Bed dimension: Rear bed, L x W, approx. cm
x 170 - 160 170 - 160
Sleeping berths 6 7
Unladen weight, approx. kg 1194 1317
Mass in running order, approx. kg 1229 1352
Maximum load, approx. kg 271 248
Technically permissible total mass kg 1500 1600
S 3004, 3.5 kW S 3004, 3.5 kW
Heating
Gas Gas
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15)
Waste water tank, approx. l 23 23
Water supply incl. boiler (reduced volume) ca. l 44 (15) 44 (15)
15465 KR up!
525 KR up!
Standard equipment
565 FMK
495 QSK
495 FR
475 FR
415 QL
475 EL
Chassis
Zinc-plated chassis with inertia braking system with reversing automatic
Chassis features
AAA self-adjusting brake
ACS stabiliser
Lightweight zinc-plated corner steadies
High-quality brand-name tyres, designed for a speed of 100 km/h
Single-axle premium steel wheel set 185 R14 C 8 PR, up to 1.600 kg
Exterior features
Glass bottle locker for 2 x 11 kg
Floor of the gas bottle locker made of rot-resistant and robust corrugated aluminium
Spare wheel carrier in gas locker
Front, rear and roof made of robust GRP
Trapezoid double-glazed windows, openable and insulated (graphite grey) with blackout and mosquito blinds
Skylight Mini Heki
One-piece habitation door
Exterior design
Sides in hammer finish, white
Access locker doors
Access locker door rear right 560x1150 mm
Access locker door front right 749x297 mm
Access locker door front left 997x419 mm
Access locker door front right 997x419 mm
Access locker door front right 1000x420 mm
Interior design
Pearlwhite wood décor
Grey Orbit upholstery
Textile equipment
Cold foam double bed mattress
7-zones cold foam mattress single bed left standard
7-zones cold foam mattress single bed right standard
Furniture layouts
AirPlus - perfect air circulation in the interior and rear ventilation of the overhead lockers and sideboards
Seating lounge converts to bed
Special slatted frame with flexible natural rubber holders, opening for optimal use of storage compartments under the beds
Spacious pull-down bed above seating lounge, with manual control
Bunk beds with safety net and ladder
Bunk bed with 2 sleeping berths, foldable
Interior features
Smoke detector
Kitchen
Practical 3-flames cooker with electric ignition
Spacious fridge with 90-litre volume and 9-litre freezer
Large fridge with 142 l volume and 15 l freezer
Spacious drawers with silent soft-close function
Bathroom
Trendy washbasin made of stainless steel
Shower tray
Skylight with mosquito net
Heating
Gas heating S 5004 with automatic ignition
16465 KR up!
525 KR up!
Standard equipment
565 FMK
495 QSK
495 FR
475 FR
415 QL
475 EL
Gas heating S 3004 with automatic ignition
Electrical installation
Awning light 12V
Additional lighting through LED spotlights
12 V power supply throughout vehicle
CEE external output socket for 230V on-board electrics
Compact power distribution unit with 230V safety device and 12V fuse box in wardrobe incl. powerful 340W transformer
LED spots in front and rear seating lounges
Water supply
Fresh water tank 44 l
Mobile 22 l waste water tank
Electric water supply
PACKAGES C´GO & C´GO UP!
Package Safety Package (9556) Safety Package (9556)
ATC Trailer Control x x
DuoControl safety gas pressure regulator with crash sensor x
DuoControl safety gas pressure regulator with crash sensor and EisEx gas
x
regulator heater
Package Autonomy Package I (10011) Autonomy Package II (10012)
Battery (95 Ah) x x
Battery charger x x
Central 12V main switch x x
Voltage display x x
Fan 12V for S 3004 x
Touring Package (7345)
Hot-water supply
Hot-air system
Shower equipment with shower fittings and curtain
Heki II skylight incl. illuminated roof lining
Flyscreen door
Indirect lighting
Optional extra Not possible Standard Mandatory
17Included in Additional Code
465 KR up!
525 KR up!
Optional extras package weight
565 FMK
495 QSK
495 FR
475 FR
415 QL
475 EL
Chassis
Weight upgrade to 1.300 kg 0 135
Weight upgrade to 1.360 kg (without chassis change) 0 9619
Weight upgrade to 1.400 kg 24 359
Weight upgrade to 1.500 kg 24 136
Weight upgrade to 1.700 kg 24 278
Weight upgrade to 1.800 kg 27 279
Weight upgrade to 1.900 kg (incl. alloy wheel 225/70R15C) 27 394
Weight upgrade to 2.000 kg (single axle incl. alloy wheel 225/70R15C) 27 138
Chassis features
ATC Trailer Control SHP 4 748
Corner steadies incl. large-area support feet 1 9138
Draw bar cover 3 434
Solid rubber support wheel with support load indicator 2 10063
Wheel trims for 14" tyres 2 276
Alloy wheel 185 R14 C LI 102, up to 1.600 kg 0 836
Single-axle premium wheel set 195R14C LI106 (with steel wheel 1.700kg and
3 832
1.800kg)
Alloy wheel 195 R14 C LI 106, 1.700 kg and 1.800 kg 2 838
Alloy wheel 225/70 R15 C LI 112, 1.900 kg and 2.000 kg 9 1093
Spare steel wheel 185 R14 C 8 PR, up to 1.600 kg 18 831
Spare alloy wheel 185 R14 C LI 102, up to 1.600 kg 17 837
Spare steel wheel 195 R14 C LI 106, 1.700 kg and 1.800 kg 19.5 833
Spare alloy wheel 195 R14 C 8PR-LI 106, 1.700 kg and 1.800 kg 19 839
Exterior features
Front window 4 982
Kitchen window, sliding (change of window shape) 2 6406
Opening window in bathroom 3 1028
Heki II skylight incl. illuminated roof lining TP 13 274
One-piece habitation door with window 0 6427
Flyscreen door TP 2.5 360
Exterior design
Smooth sides white 1 443
Smooth sides white 1 443
Access locker doors
Access locker door rear left 749x297 mm 2 1077
Access locker door rear right 749x297 mm 2 1078
Access locker door front right 1675x885 mm 0 9430
Access locker door front right 560x1150 mm 0 10393
Interior design
Blue Lagoon upholstery 0 9379
Green Paradise upholstery 0 9380
Sunshine upholstery 0 9378
Textile equipment
7-zone mattress made of heat-regulating material 0 10318
Bed cover for single bed mattresses in upholstery colour 0 6377
Bed cover for double bed mattress in upholstery colour 0 6377
Bed cover for double bed mattress and 2 bunk beds in colour of upholstery 0 6377
Bed cover for double bed mattress and 3 bunk beds in colour of upholstery 0 6377
Loose carpet 8 513
Furniture layouts
Bunk bed with 3 sleeping berths, not foldable 20 200
18Included in Additional Code
465 KR up!
525 KR up!
Optional extras package weight
565 FMK
495 QSK
495 FR
475 FR
415 QL
475 EL
4)
Seat enlargement for opposite seating lounge (in comb. with option 8699) 1 7750
Hanging table with rotating device 0 8699
Single beds convert to double bed 5 685
Multimedia
Preparation for flat screen TV (antenna cable and TV bracket) 2 678
5)
Multifunctional external connection, 12 V, 220 V, TV and SAT 1 611
Heating
Ultraheat additional heating for S 5004, electric 220 V 2 422
Electric floor heating 9 387
Ultraheat additional heating for S 3004, electric 220 V 2 364
Fan 12 V with automatic speed control for S 5004 2 178
Fan 12V for S 3004 AP 2 177
Hot-air system TP 9.5 142
Air Conditioning
Pre-wiring for A/C 0 172
Electrical installation
USB port for spotlight bar 0 9989
Water supply
City water connection 2 414
Hot-water supply TP 15 123
Shower equipment with shower fittings and curtain TP 5 1097
Gas supply
DuoControl safety gas pressure regulator with crash sensor SHP 2.5 784
DuoControl safety gas pressure regulator with crash sensor and EisEx gas regulator
SHP 2.5 784
heater
6)
Gas socket (exterior) 1 187
Gas detection system 0 10058
Packages
Safety Package 6.5 9556
Safety Package 6.5 9556
Touring Package 47 7345
7)
Autonomy Package I 32 10011
Autonomy Package II 30 10012
Accessories - Highlights (orderable via Dethleffs Original Accessories)
Retrofittable multifunctional rail 0 3269437
Caravan "cellar" 0 3103933
Organiser apron 0 3103940
Floor skirt 0 3103943
Fit cover mono axle 0 3103953
Optional extra Not possible Standard Mandatory
SHP Safety Package TP Touring Package AP Autonomy Package
19Aero
Anniversary equipment „90 Years Package“ 57 kg 410 QS 470 EL 470 FR 470 FSK 490 QSK 500 QSK 510 ER 520 ER
17" alloy wheels in Dethleffs design
Smooth sides white
Design elements for front and rear
Draw bar cover
Extra wide door with window and fly screen door
Skylight incl. lighting, 700 x 500 mm
Warm water supply with Therme
Easy to clean and silky acrylic glass kitchen rear panel
Elegant and functional textile elements for storage and
fastening
Skylight incl. illumination, Elegant and functional textile elements
700 x 500 mm for stowing and fastening
Stylish kitchen rear panel
made of acrylic glass
White smooth
sheet metal
Draw bar cover
Design attachment elements
for front and rear
17” alloy wheels in
Dethleffs design
Extra wide entrance door with Warm water supply
window and fly screen door with ThermeAero
Smile - the AERO is here Technical info*
Technically permissible total mass 1300 - 1500 kg
The traditional classic returns in the light, modern AERO look. The
Overall length, approx. 634 - 751 cm
curved rear moulding with the flush-mounted integral tail lights
seems almost like a smile, while the clear, bright interior design Overall width, approx. 230 cm
creates an equally good atmosphere. The extensive 90 Years
Overall height, approx. 261 cm
anniversary package with highlights such as 17" alloy wheels in the
Dethleffs design and an extra-wide entrance door with window and * Maximum values partly not possible for all models or only in connection with
flyscreen door is guaranteed to put you in a good mood. Refined certain options.
and popular layout solutions will make the beginning of your
caravanning journey very easy.
Upholstery Plus factors
+ A reason to celebrate: many options at an attractive price
thanks to the 90-Year Anniversary package
+ A real eye-catcher: the new, modern exterior design
turns heads and the interior design has a winning
concept
+ Fyn upholstery + Skagen upholstery
+ I know you: the well-known, sophisticated floor plan
*
solutions meet everyone's requirements
+ Winter is coming: be prepared for colder temperatures
with the optional Winter Comfort Package
+ Protects you from bad weather: roof, front and rear
made of robust GRP
+ Visby upholstery *
Wood décor
+ Maryland Oak wood décor
*optionally available
21Aero
Technical info
Aero 410 QS 470 EL 470 FR 470 FSK 490 QSK 500 QSK
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1200 kg chassis, 1360 kg chassis, 1360 kg chassis, 1500 kg chassis, 1360 kg chassis, 1500 kg
Overall length, approx. cm 634 686 695 696 720 736
Overall width, approx. cm 230 230 230 230 230 230
Overall height, approx. cm 261 261 261 261 261 261
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 39 / 28 / 28 39 / 28 / 28 39 / 28 / 28 39 / 28 / 28 39 / 28 / 28 39 / 28 / 28
Tire size 185 R14 8PR 185 R14 8PR 185 R14 8PR 185 R14 8PR 185 R14 8PR 185 R14 8PR
210 x 85 / 190 x
Bed dimension: Front bed, L x W, approx. cm 210 x 135 85 / 210 - 190 x 200 x 145 - 110 200 x 145 - 110 210 x 135 210 x 145
210
Bed dimension: Central / middle bed, L X W,
approx. - - - 190 x 100 200 x 90 190 x 90
cm
2x 210 x 80 / 2x 2x 180 x 70 / 2x 2x 210 x 80 / 2x
Bed dimension: Rear bed, L x W, approx. cm 190 x 135 210 x 130 - 100 210 x 125 210 x 80 / 180 x 70 / 210 x 80 /
210 x 70 165 x 65 210 x 70
Sleeping berths 3 3 4 5/6 5/6 5/6
Unladen weight, approx. kg 1052 1140 1163 - 1208 1196
Mass in running order, approx. kg 1087 1175 1198 - 1243 1231
Maximum load, approx. kg 213 185 162 - 257 269
Technically permissible total mass kg 1300 1360 1360 1500 1500 1500
S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW
Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6
Heating
G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas-
Electric Electric Electric Electric Electric Electric
Refrigerator volume incl. freezer, approx. l 90 (9) 142 (15) 142 (15) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 23 23 23 23 23 23
Water supply incl. boiler (reduced volume) ca. l 44 (15) 44 (15) 44 (15) 44 (15) 44 (15) 44 (15)
22Aero
Technical info
Aero 510 ER 520 ER
Lightweight Lightweight
Standard chassis
chassis, 1500 kg chassis, 1500 kg
Overall length, approx. cm 731 751
Overall width, approx. cm 230 230
Overall height, approx. cm 261 261
Headroom in living area, approx. cm 198 198
Insulation floor / side walls / roof mm 39 / 28 / 28 39 / 28 / 28
Tire size 185 R14 8PR 185 R14 8PR
200 x 85 / 190 x 200 x 85 / 195 x
Bed dimension: Front bed, L x W, approx. cm
85 / 200 x 195 85 / 200 x 195
Bed dimension: Central / middle bed, L X W, approx. cm - -
Bed dimension: Rear bed, L x W, approx. cm 210 x 145 - 90 210 x 145 - 125
Sleeping berths 4 4
Unladen weight, approx. kg 1231 1247
Mass in running order, approx. kg 1266 1282
Maximum load, approx. kg 234 218
Technically permissible total mass kg 1500 1500
S 3004, 3.5 kW S 3004, 3.5 kW
Gas / Combi 6 Gas / Combi 6
Heating
G/E, 6 kW Gas- G/E, 6 kW Gas-
Electric Electric
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15)
Waste water tank, approx. l 23 23
Water supply incl. boiler (reduced volume) ca. l 44 (15) 44 (15)
23Standard equipment
490 QSK
500 QSK
470 FSK
410 QS
470 FR
520 ER
510 ER
470 EL
Chassis
Zinc-plated chassis with inertia braking system with reversing automatic
Chassis features
ACS stabiliser
Lightweight zinc-plated corner steadies
High-quality brand-name tyres, designed for a speed of 100 km/h
Wheel trims for 14" tyres
Single-axle premium steel wheel set 185 R14 C 8 PR, up to 1.600 kg
Exterior features
Glass bottle locker for 2 x 11 kg
Space-saving gas locker door which opens upwards
Floor of the gas bottle locker made of rot-resistant and robust corrugated aluminium
Spare wheel carrier in gas locker
Front, rear and roof made of robust GRP
Standard window, graphite grey
Rear window
Opening window in bathroom
Midi Heki lift-and-tilt skylight incl. illuminated roof lining
Wide, one-piece habitation door
Exterior design
Sides in hammer finish, white
Access locker doors
Access locker door front right 1000x420 mm
Interior design
Maryland Oak wood décor
Fyn upholstery
Textile equipment
7-zone mattress made of heat-regulating material
Furniture layouts
AirPlus - perfect air circulation in the interior and rear ventilation of the overhead lockers and sideboards
Seating lounge converts to bed
Special slatted frame with flexible natural rubber holders, opening for optimal use of storage compartments under the beds
Bunk beds with safety net and ladder
Bunk bed with 2 sleeping berths, foldable
One-legged telescopic table, height adjustable
Interior features
Smoke detector
Kitchen
Spacious drawers with silent soft-close function
Large fridge with 142 l volume and 15 l freezer
Practical 3-flames cooker with electric ignition
Spacious fridge with 90-litre volume and 9-litre freezer
Bathroom
Integrated design washbasin made of solid surface material
Shower tray
Skylight with mosquito net
Heating
Hot-air system
Gas heating S 3004 with automatic ignition
Electrical installation
24Standard equipment
490 QSK
500 QSK
470 FSK
410 QS
470 FR
520 ER
510 ER
470 EL
Awning light 12V
Additional lighting through LED spotlights
USB port for spotlight bar
12 V power supply throughout vehicle
CEE external output socket for 230V on-board electrics
Compact power distribution unit with 230V safety device and 12V fuse box in wardrobe incl. powerful 340W transformer
LED spots in front and rear seating lounges
Water supply
Fresh water tank 44 l
Mobile 22 l waste water tank
Electric water supply
PACKAGES AERO
Package Safety Package (9556)
ATC Trailer Control x
DuoControl safety gas pressure regulator with crash sensor and EisEx gas regulator
x
heater
Package Autonomy Package I (10011) Autonomy Package II (10012)
Battery (95 Ah) x x
Battery charger x x
Central 12V main switch x x
Voltage display x x
Fan 12V for S 3004 x
Package Winter Comfort Package (11547) Winter Comfort Package (11547)
Hot air heating Combi 6 G/E x x
Heating operated via iNet Box (only in comb. with hot air heating Combi 4/6 G/E
x x
or hot water heating)
Digital control panel for Combi heating (G/E only) x x
Electric floor heating x x
XPS insulation for front, rear and sides x
XPS insulation for front, rear and sides x
Shower Package (6105)
Shower equipment with shower fittings and curtain
City water connection
Optional extra Not possible Standard Mandatory
25Included in Additional Code
Optional extras package weight
490 QSK
500 QSK
470 FSK
410 QS
470 FR
520 ER
510 ER
470 EL
Chassis
Weight upgrade to 1.300 kg 0 135
Weight upgrade to 1.360 kg (without chassis change) 0 9619
Weight upgrade to 1.400 kg 24 359
Weight upgrade to 1.500 kg 24 136
Weight upgrade to 1.700 kg 24 278
Weight upgrade to 1.800 kg 27 279
Chassis features
ATC Trailer Control SHP 4 748
Corner steadies incl. large-area support feet 1 9138
Draw bar cover 90 YP 3 434
Solid rubber support wheel with support load indicator 2 10063
Alloy wheel 185 R14 C LI 102, up to 1.600 kg 0 836
Single-axle premium wheel set 195R14C LI106 (with steel wheel 1.700kg and
3 832
1.800kg)
Alloy wheel 195 R14 C LI 106, 1.700 kg and 1.800 kg 2 838
Single-axle premium wheel set 215/60 R17 C LI 109 EA alloy wheel 0 11540
Exterior features
Front window 4 982
Kitchen window, sliding (change of window shape) 2 6406
Skylight incl. lighting, 700 x 500 mm 90 YP 10 11575
Wide, one-piece habitation door with window 90 YP 3 862
Flyscreen door 90 YP 2.5 457
XPS insulation for front, rear and sides WI-KO 0 179
XPS insulation for front, rear and sides WI-KO 0 179
Exterior design
Smooth sides white 90 YP 1 443
Smooth sides white 90 YP 1 443
Design element for front 90 YP 7 11262
Design element for rear 90 YP 5 11263
Access locker doors
Access locker door rear right 560x1150 mm 2.5 991
Access locker door front left 1000x420 mm 2 6415
Access locker door rear right 750x300 mm 2 6422
Access locker door front right 1675x885 mm 0 10848
Interior design
Skagen upholstery 0 11522
Visby upholstery 0 11523
Textile equipment
Loose carpet 8 513
Furniture layouts
Bunk bed with 3 sleeping berths, not foldable 20 200
Single beds convert to double bed 5 685
4)
Seat enlargement for opposite seating lounge (in comb. with option 8699) 1 7750
Hanging table with rotating device 0 8699
Multimedia
Preparation for flat screen TV (antenna cable and TV bracket) 2 678
5)
Multifunctional external connection, 12 V, 220 V, TV and SAT 1 611
Heating
8)
Digital control panel for Combi heating (G/E only) WI-KO 0 9971
Heating operated via iNet Box (only in comb. with hot air heating Combi 4/6 G/E
WI-KO 3 9960
or hot water heating) 9)
26Included in Additional Code
Optional extras package weight
490 QSK
500 QSK
470 FSK
410 QS
470 FR
520 ER
510 ER
470 EL
Hot air heating Combi 6 G/E WI-KO 15 9427
Electric floor heating WI-KO 9 387
Ultraheat additional heating for S 3004, electric 220 V 2 364
Fan 12V for S 3004 AP 2 177
Air Conditioning
Pre-wiring for A/C 0 172
Roof A/C 45 6512
Electrical installation
Indirect lighting 2 633
Water supply
City water connection DUP 2 414
Hot-water supply 90 YP 15 123
Shower equipment with shower fittings and curtain DUP 5 1097
Gas supply
DuoControl safety gas pressure regulator with crash sensor and EisEx gas regulator
SHP 2.5 784
heater
6)
Gas socket (exterior) 1 187
Gas detection system 0 10058
Packages
Safety Package 6.5 9556
Shower Package 7 6105
Autonomy Package I 32 10011
Autonomy Package II 30 10012
Winter Comfort Package 41.5 11547
Winter Comfort Package 41.5 11547
Accessories - Highlights (orderable via Dethleffs Original Accessories)
Retrofittable multifunctional rail 0 3269437
Caravan "cellar" 0 3103933
Organiser apron 0 3103940
Floor skirt 0 3103943
Fit cover mono axle 0 3103953
Optional extra Not possible Standard Mandatory
SHP Safety Package 90 YP 90 Years-Package WI-KO Winter Comfort Package AP Autonomy Package DUP Shower Package
27Camper®
The family caravan Technical info*
Technically permissible total mass 1500 - 2000 kg
With its extensive standard equipment, abundant storage space and
Overall length, approx. 691 - 942 cm
a wide range of bunk bed layouts and compact designs, the
Camper® is the ideal caravan for all those of you who love Overall width, approx. 230 - 250 cm
adventure.
Overall height, approx. 265 cm
* Maximum values partly not possible for all models or only in connection with
certain options.
Upholstery Plus factors
+ Enough space for every child: a selection of family
layouts with bunk beds
+ Better safe than sorry: exemplary Dethleffs safety
equipment
+ Cloud upholstery + Galaxy upholstery * + Good as standard: ready to go thanks to comprehensive
specifications
+ Modern interior: three classic upholstery options
+ Kitted out for all needs: our portfolio even features short
caravans less than 7 m in length
+ Mount upholstery *
Wood décor
+ Rosario Cherry wood décor
*optionally available
28Camper®
Technical info
Camper® 460 EL 470 ER 470 FR 500 QSK 510 ER 510 LE
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1600 kg
Overall length, approx. cm 691 713 713 729 766 762
Overall width, approx. cm 230 230 230 230 230 230
Overall height, approx. cm 265 265 265 265 265 265
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34
Tire size 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR
200 x 85 / 190 x 2x 200 x 85 / 200 x 85 / 190 x
Bed dimension: Front bed, L x W, approx. cm 205 x 135 210 x 135 210 x 135
85 / 190 x 210 200 x 210 85 / 190 x 210
Bed dimension: Central / middle bed, L X W,
approx. - - - 190 x 100 - -
cm
210 x 70 / 195 x
75 / 210 x 75 2x 200 x 85 /
Bed dimension: Rear bed, L x W, approx. cm 210 x 115 210 x 125 210 x 135 210 x 135
/ 210 x 80 / 195 x 210
210 x 70
Sleeping berths 3 3 4 5/6 4 4
Unladen weight, approx. kg 1190 1180 1200 1250 1265 1270
Mass in running order, approx. kg 1235 1225 1245 1295 1310 1315
Maximum load, approx. kg 265 275 255 205 190 285
Technically permissible total mass kg 1500 1500 1500 1500 1500 1600
S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW
Gas / Combi 4 Gas / Combi 4 Gas / Combi 4 Gas / Combi 4 Gas / Combi 4 Gas / Combi 4
Heating
G/E, 4 kW Gas- G/E, 4 kW Gas- G/E, 4 kW Gas- G/E, 4 kW Gas- G/E, 4 kW Gas- G/E, 4 kW Gas-
Electric Electric Electric Electric Electric Electric
Refrigerator volume incl. freezer, approx. l 142 (15) 86 (11) 142 (15) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 22 22 22 22 22 22
Water supply incl. boiler (reduced volume) ca. l 43 (15) 43 (15) 43 (15) 43 (15) 43 (15) 43 (15)
29Camper®
Technical info
Camper® 530 FSK 540 QMK 550 ESK 560 FMK 650 FMK 730 FKR
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1600 kg chassis, 1700 kg chassis, 1600 kg chassis, 1700 kg chassis, 2000 kg chassis, 2000 kg
Overall length, approx. cm 788 768 806 818 872 942
Overall width, approx. cm 230 250 230 250 250 250
Overall height, approx. cm 265 265 265 265 265 265
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34
Tire size 185 R14C 8PR 195 R14C LI106 185 R14C 8PR 195 R14C LI106 185/70 R14 LI88 185/70 R14 LI88
2x 200 x 85 /
Bed dimension: Front bed, L x W, approx. cm 200 x 135 200 x 140 200 x 155 200 x 155 200 x 155
200 x 210
Bed dimension: Central / middle bed, L X W, 200 x 75 / 2x 195
approx. 190 x 100 230 x 115 190 x 100 230 x 115 225 x 115 x 75 / 2x 195 x
cm 75
210 x 70 / 195 x 190 x 75 / 190 x 210 x 70 / 200 x 195 x 70 / 190 x 200 x 75 / 200 x
75 / 210 x 75 70 / 2x 190 x 75 75 / 210 x 75 75 / 195 x 75 70 / 2x 200 x 75
Bed dimension: Rear bed, L x W, approx. cm 230 x 155
/ 210 x 80 / / 170 x 75 / 210 x 80 / / 195 x 80 / / 195 x 75
210 x 70 210 x 70 195 x 70
Sleeping berths 5/6 5/6 5/6 5/6 5/6 7/8
Unladen weight, approx. kg 1340 1430 1390 1480 1710 1770
Mass in running order, approx. kg 1385 1475 1435 1525 1755 1815
Maximum load, approx. kg 215 225 165 175 245 185
Technically permissible total mass kg 1600 1700 1600 1700 2000 2000
S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW
Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6
G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas-
Heating Electric / Hot Electric / Hot Electric / Hot Electric / Hot Electric / Hot Electric / Hot
water heating, water heating, water heating, water heating, water heating, water heating,
6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas-
Electric Electric Electric Electric Electric Electric
86 (11) / 167 (29)
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 22 22 22 22 22 22
Water supply incl. boiler (reduced volume) ca. l 43 (15) 43 (15) 43 (15) 43 (15) 43 (15) 43 (15)
30Standard equipment
540 QMK
560 FMK
650 FMK
500 QSK
730 FKR
550 ESK
530 FSK
470 ER
470 FR
460 EL
510 ER
510 LE
Chassis
Zinc-plated chassis with inertia braking system with reversing automatic
Chassis features
AAA self-adjusting brake
ACS stabiliser
Lightweight zinc-plated corner steadies
High-quality brand-name tyres, designed for a speed of 100 km/h
Single-axle premium steel wheel set 185 R14 C 8 PR, up to 1.600 kg
Steel wheel 185/70 R14 LI 88 up to 2.000 kg
Exterior features
Front parts in gas locker area made of LFI (long fiber injection) technology, shock resistant, robust and
repair-friendly
Glass bottle locker for 2 x 11 kg
Space-saving gas locker door which opens upwards
Floor of the gas bottle locker made of rot-resistant and robust corrugated aluminium
Spare wheel carrier in gas locker
Fully-insulated wheel houses
Robust GRP roof
Sidewall skirts with integrated side-marker lamps
Trapezoid double-glazed windows, openable and insulated (graphite grey) with blackout and mosquito
blinds
Opening window in bathroom
Skylight Mini Heki
Midi Heki lift-and-tilt skylight incl. illuminated roof lining
One-piece habitation door
Flyscreen door
Exterior design
Front and rear in smooth sides white
Sides in hammer finish, white
Access locker doors
Access locker door front right 997x419 mm
Access locker door rear right 997x419 mm
Interior design
Rosario Cherry wood décor
Cloud upholstery
Textile equipment
7-zone mattress right made of heat-regulating material
7-zone mattress left made of heat-regulating material
7-zone double bed mattress made of heat-regulating material
Furniture layouts
AirPlus - perfect air circulation in the interior and rear ventilation of the overhead lockers and sideboards
Seating lounge converts to bed
Special slatted frame with flexible natural rubber holders, opening for optimal use of storage
compartments under the beds
Bunk beds with safety net and ladder
Bunk bed with 2 sleeping berths, foldable
Bunk bed with 2 sleeping berths, not foldable
One-legged telescopic table, height adjustable
Kitchen
Spacious drawers with silent soft-close function
Large fridge with 142 l volume and 15 l freezer
Practical apothecary drawers (depending on layout)
31Standard equipment
540 QMK
560 FMK
650 FMK
500 QSK
730 FKR
550 ESK
530 FSK
470 ER
470 FR
460 EL
510 ER
510 LE
Practical 3-flames cooker with electric ignition
Bathroom
Integrated design washbasin made of solid surface material
Shower tray
Skylight with mosquito net
Heating
Gas heating S 5004 with automatic ignition
Hot-air system
Gas heating S 3004 with automatic ignition
Electrical installation
Awning light 12V
USB port for spotlight bar
12 V power supply throughout vehicle
CEE external output socket for 230V on-board electrics
Compact power distribution unit with 230V safety device and 12V fuse box in wardrobe incl. powerful
340W transformer
LED light bar system 12V (on head-side of bed and in seating lounge)
Water supply
Fresh water tank 38 l
Mobile 22 l waste water tank
Hot-water supply
Electric water supply
PACKAGES CAMPER®
90 Years Package
90 Years Package Single 90 Years Package
Package Tandem Axle [2.8t]
Axle (11584) Tandem Axle (11615)
(11660)
17" alloy wheels in Dethleffs design (single axle) x
Front moulding with high attachment and roof rails x x x
Rear light carrier with high attachment and roof rails x x x
Corner steadies, 4 pieces x x x
Solid rubber support wheel with support load indicator x x x
17" alloy wheels in Dethleffs design (tandem axle) x
Alloy wheel 195/70 R14 C-LI 104, 2.200 kg to 2.800 kg x
Winter Comfort Package Combi 4 Winter Comfort Package Combi 6
Package
(10479) (9536)
Hot air heater Combi 4 G/E x
Digital control panel for Combi heating (G/E only) x x
Electric floor heating x x
XPS insulation for front, rear and sides x x
Waste water pipes insulated and heated x x
Insulated threader hose x x
Hot air heating Combi 6 G/E x
Optional extra Not possible Standard Mandatory
32Winter Comfort Package SNOW PLUS
Package Winter Comfort Package SNOW (5459)
(5551)
Hot-water heating x x
Electric floor heating x
Waste water pipes insulated and heated x x
XPS insulation for front, rear and sides x x
Hot-water floor heating (only in comb. with option 205) x
Mover Autonomy Package single axle Mover Autonomy Package tandem
Package
(5560) axle (5561)
Mover manoeuvring support for single-axle x
Electric autonomy equipment x x
Mover manoeuvring support for tandem-axle x
Water and Electric Autonomy Package Water and Electric Autonomy Package
Package
Combi 4 (11031) Combi 6 (11032)
Hot air heater Combi 4 G/E x
Digital control panel for Combi heating (G/E only) x x
Electric autonomy equipment x x
Fresh water tank 70 l x x
Hot air heating Combi 6 G/E x
Safety Package (8950)
ATC Trailer Control
DuoControl safety gas pressure regulator with crash sensor and EisEx gas regulator heater
Smoke detector
Shower Package (6105)
Shower equipment with shower fittings and curtain
City water connection
33Included in Additional Code
Optional extras
540 QMK
package weight
560 FMK
650 FMK
500 QSK
730 FKR
550 ESK
530 FSK
470 ER
470 FR
460 EL
510 ER
510 LE
Chassis
Weight upgrade to 1.600 kg 24 322
Weight upgrade to 1.700 kg 24 278
Weight upgrade to 1.800 kg 27 279
Weight upgrade to 1.900 kg (incl. alloy wheel 225/70R15C) 27 394
Weight upgrade to 2.000 kg (single axle incl. alloy wheel
27 138
225/70R15C)
Weight upgrade to 2.200 kg 18 6351
Weight upgrade to 2.500 kg 18 496
Weight upgrade to 2.800 kg 18 7713
Chassis features
ATC Trailer Control SHP 4 748
Corner steadies, 4 pieces 90' 1 6348
Draw bar cover STP 3 434
Solid rubber support wheel with support load indicator 90' 2 10063
Wheel trims for 14" tyres 2 276
Alloy wheel 185 R14 C LI 102, up to 1.600 kg 0 836
Single-axle premium wheel set 195R14C LI106 (with steel wheel
3 832
1.700kg and 1.800kg)
Alloy wheel 195 R14 C LI 106, 1.700 kg and 1.800 kg 2 838
Alloy wheel 225/70 R15 C LI 112, 1.900 kg and 2.000 kg 9 1093
Alloy wheel 185/70 R14 LI 88, up to 2.000 kg 0 840
Tandem-axle premium wheel set 195/70R14 C-LI104 (with steel
6 858
wheel 2.200 kg to 2.800 kg)
Alloy wheel 195/70 R14 C-LI 104, 2.200 kg to 2.800 kg 90' 4 859
Spare steel wheel 185 R14 C 8 PR, up to 1.600 kg 18 831
Spare alloy wheel 185 R14 C LI 102, up to 1.600 kg 17 837
Spare steel wheel 195 R14 C LI 106, 1.700 kg and 1.800 kg 19.5 833
Spare alloy wheel 195 R14 C 8PR-LI 106, 1.700 kg and 1.800 kg 19 839
Spare alloy wheel 225/70 R15 C LI 112, 1.900 kg and 2.000 kg 23.5 1092
Spare steel wheel 185/70 R14 LI 88, up to 2.000 kg 18 835
Spare alloy wheel 185/70 R14 LI 88, up to 2.000 kg 18 841
Spare steel wheel 195/70 R14 C-LI 104, 2.200 kg to 2.800 kg 20 860
Spare alloy wheel 195/70 R14 C-LI 102, 2.200 kg to 2.800 kg 19 861
Breakdown kit 1 620
Exterior features
Front window 4 982
Front window (bed area), if washroom in front 5 855
Rear window 4 1108
10)
Flush-fitting windows 3 7561
Heki II skylight incl. illuminated roof lining 8 274
One-piece habitation door with window 3 862
XPS insulation for front, rear and sides WI-KO 0 179
XPS insulation for front, rear and sides 0 179
Cassette awning 3750x2500 mm, manual 25.5 6928
Cassette awning 4000x2500 mm, manual 27.5 6928
Cassette awning 4500x2500 mm, manual 30 6928
Cassette awning 5500x3000 mm, manual 50.6 6928
Cassette awning 6000x3000 mm, manual 54.6 6928
Exterior design
Smooth sides white STP 1 443
Smooth sides white STP 1 443
Smooth sides titanium silver metallic STP 1 659
Smooth sides titanium silver metallic STP 1 659
34Included in Additional Code
Optional extras
540 QMK
package weight
560 FMK
650 FMK
500 QSK
730 FKR
550 ESK
530 FSK
470 ER
470 FR
460 EL
510 ER
510 LE
Front moulding with high attachment and roof rails 90', STP 1 627
Rear light carrier with high attachment and roof rails 90', STP 11 624
Manoeuvring handles in chrome design STP 0 754
Access locker doors
Access locker door front left 648x348 mm 2 1071
Access locker door rear left 749x297 mm 2 1077
Access locker door rear right 749x297 mm 2 1078
Access locker door front left 997x419 mm 2.2 1079
Access locker door front left 1069x299 mm 2 1083
Access locker door front right 1069x299 mm 2 1084
Access locker door rear left 1069x299 mm 2 1085
Access locker door rear right 1069x299 mm 2 1086
Access locker door 1550x1050 mm with window 8 9486
Interior design
Galaxy upholstery 0 11269
Mount upholstery 0 11270
Textile equipment
7-zone mattress right made of heat-regulating material wiwth
5 8216
watergel cover
7-zone mattress left made of heat-regulating material with
2 8215
watergel cover
7-zone double bed mattress made of heat-regulating material
4 8214
with watergel cover
Corner head rests for U-shaped seating lounge 2 9236
Loose carpet 8 513
Furniture layouts
Slatted bed frame with adjustable head section 1 871
Bunk bed with 3 sleeping berths, not foldable 20 200
Bunk bed with 2 sleeping berths, not foldable, instead of seating
0 9775
lounge
Single beds convert to double bed 5 685
Interior features
Smoke detector SHP 0.5 8949
2 kg fire extinguisher 3.5 843
Kitchen
Extractor fan 3 785
Oven 17 572
Kitchen unit with large fridge (175 l), separate freezer and electric
18 429
ignition
Kitchen worktop extension, foldable 1 1107
Bathroom
Bathroom in alternative design 4 604
Multimedia
FS-SAT system Voyager 65 Digimatic 10 1049
SAT parabol antenna flat 65 Easy 65 Twin 14 879
Preparation for flat screen TV (antenna cable and TV bracket) 2 678
Multifunctional external connection, 12 V, 220 V, TV and SAT 1 611
Flat screen TV 22" incl. DVD player and receiver 3.5 1103
Heating
WEA-P,
Hot air heater Combi 4 G/E 15 10480
WI-KO
8) WEA-P,
Digital control panel for Combi heating (G/E only) 0 9971
WI-KO
35Included in Additional Code
Optional extras
540 QMK
package weight
560 FMK
650 FMK
500 QSK
730 FKR
550 ESK
530 FSK
470 ER
470 FR
460 EL
510 ER
510 LE
Heating operated via iNet Box (only in comb. with hot air heating
3 9960
Combi 4/6 G/E or hot water heating) 9)
WEA-P,
Hot air heating Combi 6 G/E 15 9427
WI-KO
11)
Hot-water floor heating (only in comb. with option 205) WI-KO 10 674
Ultraheat additional heating for S 5004, electric 220 V 2 422
Electric floor heating WI-KO 9 387
Ultraheat additional heating for S 3004, electric 220 V 2 364
Hot-water heating WI-KO 40 205
Fan 12 V with automatic speed control for S 5004 2 178
Fan 12V for S 3004 2 177
Air Conditioning
Pre-wiring for A/C 0 172
Roof A/C 35 8145
Electrical installation
WEA-P, M-
Electric autonomy equipment 38 492
P
Indirect lighting 2 633
Water supply
Fresh water tank 70 l WEA-P 2.5 592
Waste water pipes insulated and heated WI-KO 5 520
City water connection DUP 2 414
Exterior shower 2 396
Shower equipment with shower fittings and curtain DUP 5 1097
Gas supply
DuoControl safety gas pressure regulator with crash sensor and
SHP 2.5 784
EisEx gas regulator heater
Gas socket (exterior) 1 187
Packages
90 Years Package Single Axle 25 11584
90 Years Package Tandem Axle 22 11615
90 Years Package Tandem Axle [2.8t] 19 11660
Safety Package 7 8950
Shower Package 7 6105
Water and Electric Autonomy Package Combi 4 55.5 11031
Water and Electric Autonomy Package Combi 6 55.5 11032
Mover Autonomy Package single axle 70 5560
Mover Autonomy Package tandem axle 98 5561
Winter Comfort Package Combi 4 45 10479
Winter Comfort Package Combi 6 45 9536
Winter Comfort Package SNOW 71 5459
Winter Comfort Package SNOW PLUS 72 5551
Accessories - Highlights (orderable via Dethleffs Original Accessories)
Retrofittable multifunctional rail 0 3269437
Caravan "cellar" 0 3103933
Organiser apron 0 3103940
Floor skirt 0 3103943
Fit cover mono axle 0 3103953
Fit cover tandem axle 0 3103954
Optional extra Not possible Standard Mandatory
SHP Safety Package 90' 90 Years-Package STP Styling Package WI-KO Winter Comfort Package WEA-P Water and Electric Autonomy Package M-P Mover Package DUP Shower Package
36Nomad
Experience pays off Technical info*
Technically permissible total mass 1500 - 2200 kg
With its comprehensive equipment and stylish, detailed solutions,
Overall length, approx. 691 - 942 cm
the Nomad is the perfect caravan for demanding travellers. One
highlight is the sophisticated Light Moments lighting concept, which Overall width, approx. 230 - 250 cm
is stylishly designed for the ultimate feel-good mood - regardless of
Overall height, approx. 265 cm
the weather!
* Maximum values partly not possible for all models or only in connection with
certain options.
Upholstery Plus factors
+ Something for everyone: a wide range of caravans with
double and single-bed layouts
+ Sophisticated exterior design: chic details such as a
designer rear moulding with integrated lights, chrome
trim on the side walls and chrome manoeuvring handles
+ Ruby upholstery + Champion
+ Well-being atmosphere: exquisite, elegant living room
upholstery *
design with atmospheric light concept
+ Cooking like at home: very well-equipped gourmet
kitchen with illuminated kitchen back panel
+ Good as standard: ready to go thanks to comprehensive
specifications
+ Chromo upholstery
*
Wood décor
+ Noce Nagano wood décor
*optionally available
37Nomad
Technical info
Nomad 460 EL 470 FR 490 BLF 490 EST 510 ER 510 LE
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1500 kg chassis, 1600 kg
Overall length, approx. cm 691 713 729 729 766 762
Overall width, approx. cm 230 230 230 230 230 230
Overall height, approx. cm 265 265 265 265 265 265
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34
Tire size 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR 185 R14C 8PR
200 x 85 / 190 x 200 x 85 / 190 x 200 x 85 / 190 x
Bed dimension: Front bed, L x W, approx. cm 200 x 135 - 210 x 135
85 / 190 x 210 85 / 190 x 210 85 / 190 x 210
Bed dimension: Central / middle bed, L X W,
approx. - - 185 x 105 185 x 90 - -
cm
2x 200 x 85 /
Bed dimension: Rear bed, L x W, approx. cm 210 x 115 210 x 135 210 x 135 - 210 x 135
200 x 215
Sleeping berths 3 4 3 3 4 4
Unladen weight, approx. kg 1230 1235 1315 1280 1315 1335
Mass in running order, approx. kg 1275 1280 1360 1325 1360 1380
Maximum load, approx. kg 225 220 140 175 140 220
Technically permissible total mass kg 1500 1500 1500 1500 1500 1600
S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW S 3004, 3.5 kW
Gas / Combi 4 Gas / Combi 4 Combi 4 G/E, 4 Combi 4 G/E, 4 Gas / Combi 4 Gas / Combi 4
Heating
G/E, 4 kW Gas- G/E, 4 kW Gas- kW Gas-Electric kW Gas-Electric G/E, 4 kW Gas- G/E, 4 kW Gas-
Electric Electric Electric Electric
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15) 142 (15) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 22 22 22 22 22 22
Water supply incl. boiler (reduced volume) ca. l 43 (15) 43 (15) 48 (15) 48 (15) 43 (15) 43 (15)
38Nomad
Technical info
Nomad 520 ELT 530 DR 560 FMK 560 RET 650 RQT 730 FKR
Lightweight Lightweight Lightweight Lightweight Lightweight Lightweight
Standard chassis
chassis, 1700 kg chassis, 1600 kg chassis, 1700 kg chassis, 1700 kg chassis, 2000 kg chassis, 2200 kg
Overall length, approx. cm 762 788 818 818 872 942
Overall width, approx. cm 250 230 250 250 250 250
Overall height, approx. cm 265 265 265 265 265 265
Headroom in living area, approx. cm 198 198 198 198 198 198
Insulation floor / side walls / roof mm 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34 42 / 34 / 34
195/70 R14C
Tire size 195 R14C LI106 185 R14C 8PR 195 R14C LI106 195 R14C LI106 185/70 R14 LI88
LI104
200 x 85 / 190 x
Bed dimension: Front bed, L x W, approx. cm 205 x 150 200 x 155 230 x 150 230 x 155 200 x 155
85 / 190 x 210
Bed dimension: Central / middle bed, L X W, 200 x 75 / 2x 195
2x 200 x 85 /
approx. 185 x 90 - 230 x 115 200 x 155 x 75 / 2x 195 x
200 x 210
cm 75
195 x 70 / 190 x
75 / 195 x 75
Bed dimension: Rear bed, L x W, approx. cm - 210 x 135 - - 230 x 155
/ 195 x 80 /
195 x 70
Sleeping berths 3 4 5/6 4 4 7/8
Unladen weight, approx. kg 1400 1350 1505 1500 1715 1810
Mass in running order, approx. kg 1445 1395 1550 1545 1760 1855
Maximum load, approx. kg 255 205 150 155 240 345
Technically permissible total mass kg 1700 1600 1700 1700 2000 2200
S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW S 5004, 6 kW
Combi 6 G/E, 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6 Gas / Combi 6
kW Gas-Electric / G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas- G/E, 6 kW Gas-
Heating Hot water Electric / Hot Electric / Hot Electric / Hot Electric / Hot Electric / Hot
heating, 6.4 kW water heating, water heating, water heating, water heating, water heating,
Gas-Electric 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas- 6.4 kW Gas-
Electric Electric Electric Electric Electric
86 (11) / 167 (29)
Refrigerator volume incl. freezer, approx. l 142 (15) 142 (15) 142 (15) 142 (15) 142 (15)
Waste water tank, approx. l 22 22 22 22 22 22
Water supply incl. boiler (reduced volume) ca. l 48 (15) 43 (15) 43 (15) 43 (15) 43 (15) 43 (15)
39You can also read
