OBJECTIVE                                The CUI-JIP will consist of three        Theme 1 objectives
                                                                                                                                    research themes, as follows.             The goals of Theme 1 are
                                                                                           The CUI-JIP will develop multifaceted                                             to i) advance a mechanistic
                                                                                           CUI management strategies                                                         understanding of how operating and
                                                                                           covering monitoring, prediction, and
                                                                                                                                    RESEARCH THEMES                          environmental conditions influence
                                                                                           mitigation. Specifically, the CUI-JIP    Theme 1: Coating degradation             coatings’ behaviour and ii) develop
Corrosion under insulation (CUI) is considered an insidious                                will advance our understanding of
                                                                                           the CUI mechanisms and enable
                                                                                                                                    and life prediction                      a predictive tool for estimating the
                                                                                                                                                                             coating remaining life to assist
                                                                                                                                    The use of protective coatings,
threat to many industries, which accounts for around 40 to                                 transformative solutions to the
                                                                                           industry.
                                                                                                                                    both organic and metallic, is the        with inspection planning and
                                                                                                                                                                             prioritisation.
60% of the total cost of piping maintenance1.
                                                                                                                                    primary means for controlling
                                                                                                                                    external corrosion of assets. Indeed,    Theme 1 scope
                                                                                                                                    coatings are regarded as the most
                                                                                           CURTIN CORROSION CENTRE                  important barrier to prevent CUI4.       A non-identifying database of
The presence of insulation materials and jacketing creates an annular space where water    (CCC)                                    Unfortunately, coatings often            existing coatings—e.g., chemistry,
                                                                                                                                    degrade in the aggressive under          application and maintenance history,
can accumulate and be in contact with the steel substrate. Over time, corrosion proceeds                                            insulation conditions, leading to        their service life and exposure
                                                                                           The interdisciplinary research team
undetected and failure occurs. Despite the vast amount of research and development on                                               defects and the potential to the         conditions—will be populated
                                                                                           at the Curtin Corrosion Centre
                                                                                                                                    localization of the corrosion attack5.   from information provided by JIP
mitigation, CUI remains a recurrent unresolved problem.                                    has developed world-class unique
                                                                                                                                                                             participants. Laboratory aging
                                                                                           research facilities to investigate all   Coatings used under thermal              studies will provide a mechanistic
                                                                                           aspects of CUI including, the choice     insulation are exposed to high           understanding of coating
                                                                                           of insulation materials, effects of      temperature, extreme temperature         degradation. The project will conduct
                                                                                           wet-dry cycles, extreme thermal          fluctuations, and wet/dry cycles,        field exposure at sites nominated
                                                                                           variations, coatings (both organic and   which affect their long-term             by JIP members to evaluate the
                                                                                           metallic) performance, the efficacy      performance. The constant actions        combined effects of environmental
                                                                                           of volatile corrosion inhibitors and     of evaporation and condensation          and operating parameters on the
                                                                                           self-inhibiting thermal insulations,     impose cyclical stress from thermal      behaviours of selected coating
                                                                                           in situ CUI monitoring using sensors,    expansion and contraction on to          systems. The comprehensive
                                                                                           data analytics, and atmospheric          the coating and substrate. There is,     results from laboratory ageing, field
                                                                                           corrosion simulations including          unfortunately, limited information       exposure, and maintenance database
                                                                                           UV exposures, etc. We have used          on coating degradation mechanisms        will be used to develop a coating life
                                                                                           these facilities to support industry     and rates in conditions relevant to
                                                                                           partners by, e.g., validating the                                                 prediction model.
                                                                                                                                    thermal insulation applications.
                                                                                           benefits of drain holes1, evaluating
                                                                                           the behaviour of insulation materials
                                                                                           under simulated CUI environment2,
                                                                                           demonstrating the feasibility of
                                                                                           electrochemical techniques in CUI
                                                                                           real-time monitoring2, and quantify
                                                                                           the efficacy of inhibitors and self-
                                                                                           inhibiting thermal insulation3.

2                                                                                                                                                                                                                   3
STRATEGIC RESEARCH COLLABORATION - CORROSION UNDER INSULATION (CUI) - Make tomorrow better - Curtin Corrosion Centre
INDUSTRY 4.0 FOR                         Theme 2 objectives                         variables affect the likelihood of CUI
                                                                                    and its extent. A CUI risk prediction
CUI MANAGEMENT                           The objective of Theme 2 is to develop
                                                                                    tool will be developed based on the
                                         a best practice for CUI detection based
Theme 2: Sensors and Monitoring                                                     mechanistic knowledge gained in this
                                         on market-ready real-time monitoring

                                                                                                                                  “The CUI
Conventional CUI management relies                                                  JIP, maintenance history, and sensor
                                         technologies.
on periodic inspection, which can                                                   data inputs.
be quantitative (e.g., complete or
partial removal and visual inspection,   Theme 2 scope
                                                                                    Theme 3 scope
radiography, etc.) or qualitative
(e.g., nuclear magnetic resonance
or thermography, etc.). Risk-based
                                         The first activity will be to collect
                                         information on the monitoring
                                         programs currently utilised by JIP
                                                                                    The scope of this phase will be divided
                                                                                    into two parts: (i) model development
                                                                                    and (ii) model validation.
                                                                                                                                   management
                                                                                                                                   cost may be
inspection methodologies such            participants. A comparative review
as those described in API 581 and        of the current practices and other
API 583, are commonly used to            commercially available sensors             1. Model development
                                                                                    Theme 3 will review existing external

                                                                                                                                   reduced if
identify when and where to inspect.      and data collection technologies
Incorporating relevant in-situ           will provide insights to the benefits      corrosion prediction frameworks
monitoring can aid that decision         and shortfalls of each solution. A         and modify them to account for
process, which, in turn, can increase    pilot scale CUI rig of varying piping      the conditions that lead to CUI. For

                                                                                                                                   unnecessary
the effectiveness of inspection and      configurations will be utilised            example, models based on machine
reduce CUI risks.                        to develop the best monitoring             learning and Bayesian networks
                                         strategies. Sensor data will also serve    will consider (i) water diffusion and

                                                                                                                                   direct physical
Sensor and data acquisition              as inputs of a predictive maintenance      evaporation rates under various forms
technologies have improved               machine learning-based engine.             of insulation materials to improve wet-
drastically. Today, several of the old                                              dry cycle prediction, (ii) the acceleration
                                                                                    of the anodic reaction, (iii) the influence

                                                                                                                                   assessments are
“pain points” have been overcome.        Theme 3: Predictive maintenance
Sensors can be deployed to monitor                                                  of electrolyte thickness, etc. Other
                                         Risk-based methods are
tell-tale signs of CUI such as (i) the                                              contributing factors such as insulation
                                         conventionally used to prioritise
presence of water, (ii) metal loss,                                                 materials, pipe geometry, environment,
                                         high-risk areas for CUI inspection and

                                                                                                                                   minimised.”
(iii) electrochemical and chemical                                                  operating temperature and insulation
                                         rectification. Probabilistic models
activity, and operating parameters                                                  condition will also be incorporated.
                                         and backpropagation approaches
(temperature, pH, internal pressure,     are sometimes incorporated to fine-
etc.). Moreover, sensor data can be      tune the prediction outcomes6. Yet,        2. Model validation and training
used to train predictive models.         maintenance approaches remain              Machine learning algorithms will
                                         only partially effective and are costly.   also be trained based on fuzzy data
                                         The CUI management cost may be             extracted from, for example, past
                                         reduced if unnecessary direct physical     inspections and maintenance records,
                                         assessments are minimised.                 engineering reports, visual rankings,
                                                                                    end-user experience, etc. The data
                                                                                    will be anonymized and treated as
                                         Theme 3 objectives
                                                                                    confidential. Specific information
                                         The objective of Theme 3 is to improve     related to locations and projects will
                                         our understanding of how interrelated      be removed.
                                         operating and environmental

4                                                                                                                                                5
STRATEGIC RESEARCH COLLABORATION - CORROSION UNDER INSULATION (CUI) - Make tomorrow better - Curtin Corrosion Centre
PROJECT GOVERNANCE
                    The CUI-JIP steering committee will
                    consist of representatives from the
                    JIP participants and Dr Thunyaluk
                    Pojtanabuntoeng and Prof. Mariano
                    Iannuzzi as Curtin Corrosion Centre
                    delegates. Monthly updates will be
                    provided via a project management
                    portal. Project updates will be
                    presented in technical workshops to
                    be held twice per year.

                    • Participation fee: AU$60,000 per
                      annum
                    • Deadline Expression of Interest:
                      15 March 2021
                    • Contract negotiations: March-
                      September 2021
                    • CUI-JIP Kick-off: January 2022
                    • Duration: 3 years
                    • A minimum of 5 companies is
                      required.

“Sensor data
 will be used to
 train predictive
 models.”
