Horse trailers Master Catalogue - Plywood, aluminium, full-poly models, large trailers and carriages
Horse trailers
  Master Catalogue
  Plywood, aluminium, full-poly models,
  large trailers and carriages

7000 series
Horse trailers Master Catalogue - Plywood, aluminium, full-poly models, large trailers and carriages
Allow us to convince you
                                               Our arguments make it easy for you to
                                               become a convinced fan of high-quality
                                               Humbaur products.

                                               30 years of experience                                                 Enthusiastic customer service
                                               For the past three decades, we have been among the leading             Your nearby specialist dealer can provide you with trailers up to
                                               manufacturers of passenger vehicle trailers. Over 700,000 trailers     3.5 t. Owners of trailers with a gross weight of over 5 t can make
                                               have left our premises since the establishment of our company.         use of our direct service. Whether you need a spare part or have
                                               We now manufacture approximately 50,000 units per year.                questions about applications – we and your local dealer are there
                                               You will be able to discover this abundance of experience in           to assist you.
                                               each of our trailers.
                                                                                                                      High-quality components
                                               High quality                                                           Quality is in the detail, which is why Humbaur only makes use
                                               Robust and long lasting – these are the qualities a trailer needs      of high-quality vehicle components made by well-known
                                               to have. We achieve this goal by using excellent components            manufacturers. We are continuously exchanging experiences
                                               and first-class manufacturing processes. We inspect each trailer       with our suppliers. This allows us constantly to optimise products.
                                               in ­detail before delivering it.
                                                                                                                      Made in Germany
                                               Multiple transport solutions                                           Whether you decide on one of our 420 serial models or
                                               Our products cover a particularly wide range of applications.          ­commission a special model customised to your individual
                                               Are you looking for a trailer for private or business use? Then you    requirements: We develop and manufacture all our trailers in
                                               will find a suitable model for a wide range of applications with us.   accordance with the latest state of technology. You will receive
                                               Choose between a permissible gross weight of 750 kg to 40 t.           ­top-class quality "made in Germany".

Follow Humbaur!                                Large selection of accessories
                                               Do you have a lot of individual requirements for your trailer?
The horse trailer specialist.                  With our many suitable accessories, each customer can extend
Viktoria Lundquivst, equestrienne, Stockholm   our comprehensive range of serial accessories to suit his needs.
