Helium – Macro View December 2017 Published by Edison Investment Research
Helium – Macro View Elemental analysis
Fragility of supply/demand picture to continue Oil & gas/Industrials
19 December 2017
After three years of oversupply, 2017 has seen a notable tightening in the
helium market caused by plant outages and the Qatari blockade, triggering
price increases from major industrial companies. Despite an opaque Report summary
picture making forecasting difficult, we believe the balance is weighted Helium is a vital element in the manufacture of
towards a tightening market, as little new supply will come online to offset MRIs, semiconductors as well as being critical for
space exploration, rocketry and high-level science.
declines elsewhere, in spite of large additions from mega projects in Qatar
We examine the supply/demand picture for helium,
and Russia planned from 2020 onwards. Assumed annual demand growth examining key supply sources in the US and
of 1.5% will continue to put pressure on the supply/demand balance in the globally. We also summarise the reserve situation
longer term and should support prices, motivating further development for helium and look for pricing guidance.
and helium exploration. If the mega projects are delayed (very possible),
Analyst
the picture could deteriorate further, pushing the market into substantial
Will Forbes +44 (0)20 3077 5749
deficit.
wforbes@edisongroup.com
Supply constrained, deficits likely
Helium is a vital and irreplaceable element in many critical modern components
industries.The era of supply being underwritten by the drawdown of US strategic
reserves is nearly over, and replacing the supply is not straightforward. New
(medium-term) supply is largely as a by-product of planned oil and gas mega
projects that are open to delays. While a number of companies have appeared in
recent years (mostly in the Western US and Canada) almost all are at the pre-drill
stage or focused on projects with limited potential. Many have announced grand
plans, but few have progressed to proving up gas resources, which will take time.
Opaque & oligopolistic supply impedes easy analysis
Five major fields/facilities (BLM storage, LaBarge, Hugoton, Algeria and Qatar)
supply around 80% of global upstream helium. A similar number of large players
control the distribution, which is often executed on privately negotiated contracts.
Data on current supply/demand/prices are therefore not widely disclosed and
create uncertainty around exact estimates. However, our analysis of project
developments suggests a lack of new supply to satisfy increasing (price-inelastic)
demand. We think news from large market participants lends some credibility to our
conclusions (eg Air Products contracted to buy over 75% of the 2018 volumes in
the July 2017 auction and Praxair has reportedly increased its prices from 2018).
Demand steady, prices should be supported
We have little information on demand, but see a continued increase backstopped
by helium’s lack of substitutes in its main markets of MRIs, high-end science/
engineering, pressure/purge applications and semiconductors. We can try to infer
the balance of the market from price reports. A well documented shortage in 2011-
13 forced price spikes. New supply (based on LNG plant start-ups) then came
online and prices returned to more normal levels. However, we believe the supply- This report has been
constrained picture we see in the near to medium term should see continued commissioned by North
support for pricing and may see marked increases. Our analysis indicates an American Helium as a third-
increasing shortage in the market in 2018-21 and possibly beyond, especially if the party review of global helium
mega projects at Qatar and particularly Russia (Amur) are delayed, which we think supply and demand
is very likely given delays seen in similar-sized projects historically.Summary
In this report, we detail our views on supply and demand for helium over the next 10 years,
examining major sources in the US and globally. Few projects will come online in the next three to
four years, putting increased stress on the market as the sale of stocks held in the US strategic
reserve finally ends (held in the Cliffside field, operated by the Bureau of Land Management, BLM).
We review the key sources of current and future supply to examine critical components.
Helium supply is structurally fragile, as an outage of one (of the limited number of) supplier could
have outsized effects. The impact of the Qatar blockade seems to have been contained as a new
route was found quickly, but the underlying tensions in the region remain. Other majors sources
(such as Hugoton or the BLM storage) are now at/towards the end of their lives and it is not clear
how the reservoirs will react to increasingly low pressures. It is possible that the fields will decline
far faster than we model and that the reserves estimates will not be recovered fully.
Algeria supplies over 10% of the market, but supplies of helium are dependent on the volumes of
LNG produced, which are of secondary importance to piped gas to Europe. The gas explosion in
Austria in mid-December 2017 (causing Italy to issue a state of emergency) could easily mean that
Algeria increases its piped gas to the detriment of LNG (and therefore helium) supplies.
All fields/plants will need to go down for periodic maintenance. As the information is not publicly
disclosed, it is possible that one of the large suppliers may reduce volumes markedly in coming
periods, which could affect the market.
There are few ways in which this picture could improve; there is little potential for existing projects
to expand materially and although a number of small helium exploration companies have
announced grands plans, few have proven reserves of the size that would materially move the
needle in the event of delays from Qatar and Russia.
We then summarise the reserves picture. While it is estimated that there is plenty of helium in the
world, the accessibility and commerciality of these reserves are more complex. Reserve
replacement of helium has been very poor and hampered by a number of factors:
Helium is scarce and generally found within conventional natural gas reservoirs in small
concentrations (seen in the industry in the spike of 2011-13 may have left the rump of demand more inelastic to
price movements. Indeed, despite the current looser supply/demand dynamics, pricing has not
retreated and BLM auction prices rose around 10% in July 2017 (vs previous year).
Appendices include a history of the BLM and some notes on the Helium Extraction Act 2017.
Fragility of supply/demand picture to continue
The helium industy is an opaque one, with oligopolies of large companies and nations controlling
upstream and downstream supply. There are no independent authorities that accurately trace
supply and demand as seen in other industries (eg the IEA, in the case of oil). The vast bulk of
production is not disclosed publicly, either because the players are so big that helium production is
not relevant to investors (ExxonMobil’s LaBarge facility, or Linde/Air Products businesses) or
because entities are not listed (for example, the Qatari/Algerian LNG production). As a result, there
is no clear picture of supply or demand. Additionally, estimates on key variables such as helium
concentration, productive capacity or timelines for expansion often vary between two forecasters for
the same facility. Outages in productive capacity are rarely reported widely or on a timely basis,
while many future projects will likely be dependent on the level of natural gas prices to be
sanctioned or expanded.
We do know that supplies from major sources (Hugoton and the BLM storage facility) are definitely
declining. New sources of supply are limited and will not offset these falls, meaning near-term
supply will certainly decrease, and the only projects that could reverse this picture are mega
projects (Qatar III and Amur in Russia), which are liable to delays. Our study of other large oil and
gas developments worldwide shows material delays are commonplace, so the 2021 start-up of
Amur may be at risk, we think. If this is delayed it will have a significant effect on the helium market.
The demand side is equally difficult to pin down accurately, but there have been no reports of
sharply increasing prices of the type seen in 2012 (despite the Qatari blockade in mid-2017),
suggesting the market was broadly in balance in 2017.
In the longer term, major additions such as Helium III (Qatar, 2020) and Amur (Russia, 2021) will
create material new helium sources, but the next few years are likely to bring little new incremental
supply to cover reducing supply from existing sources and any demand increases (which we
assume will be 1.5% pa, in line with historical increases). There is, therefore, potential for a deficit
before then, which would be exacerbated by any downtime (such as further issues with Qatar or
unexpected downtime in other major producers).
Helium – Macro View | 19 December 2017 3Exhibit 1: Estimated global supply/demand forecast, mmcf/year
9,000
8,000
7,000
6,000
5,000
4,000
mmcf/yr
3,000
2,000
1,000
0
2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027
US BLM Storage Hugoton Field LaBarge
US CO2 Other US Qatar
Australia Algeria Poland
Russia South Africa Canada
Demand - 0% growth from 2016 Demand - 1.5% growth from 2016 Demand - 3% growth from 2016
Source: JR Campbell & Associates report for BLM Office of Minerals Evaluation, public and private company
data, Edison Investment Research, various
Our base case sees a deficit building from 2017 onwards, only (partially) offset by increased
production from Qatar’s Helium III in 2020, but more importantly the volumes coming from Amur
Gas development in 2021/2022 onwards. While we currently model Amur’s volumes coming online
in mid-2021 (as currently forecast by GazProm), the effect of possible delays would be very
material on the supply demand balance. For example, if we were to delay the Amur volumes by 24
months (industry studies show an average delay on projects of 20months), the picture become one
of severe deficit out to 2027, as seen below. Indeed, under this scenario, the market would only be
in balance with no demand growth whatsoever, which we see as very unlikely.
Exhibit 2: Estimated global supply/demand forecast under a delayed Amur scenario
(24months), mmcf/year
9,000
8,000
7,000
6,000
5,000
4,000
mmcf/yr
3,000
2,000
1,000
0
2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027
US BLM Storage Hugoton Field LaBarge
US CO2 Other US Qatar
Australia Algeria Poland
Russia South Africa Canada
Demand - 0% growth from 2016 Demand - 1.5% growth from 2016 Demand - 3% growth from 2016
Source: Source: JR Campbell & Associates report for BLM Office of Minerals Evaluation, public and private
company data and Edison Investment Research, various
If readers were to assume a 3% demand growth, deficits would grow even if Amur and Qatar came
online as currently expected, while any delays would leave the deficit at around 1bcf/yr by 2027.
We have seen some action from some market participants that may indicate their preparation for
shortages to cover possible market gaps (for example, Air Products bought 75% of the recent BLM
auction for 2018 volumes). The market remains very susceptible to supply disruption.
Helium – Macro View | 19 December 2017 4Key supply sources/projects
Our analysis of major production facilities globally indicates little new (guaranteed) supply will come
online in coming years (DBK, Tenawa), with incremental supply primarily going towards offsetting
declines eslewhere (BLM, Hugoton). We review the major sources below.
United States
The US has been the key source for helium for decades. However, the depletion of the strategic
reserve (and other major fields), together with the new supply from Qatar has lessened its role.
BLM – the strategic reserve will be fully depleted by 2021 (except for 3bcf of strategic reserve,
which is to be used only when critical, and some privately held reserves). After auctions in July
2017 (and the conservation sales), production in 2018 will be around 900mcf/yr, leaving only
1
around 400mmcf/yr to be sold in 2019, to keep within the federally mandated 3bcf limit of strategic
reserves. As of October 2017, reserves of helium in the system were 3.475bcf (government) and
3.642bcf (private). After this limit is reached, only the private storage will be released. As a result,
we assume 200mmcf/yr will be released each year from private sources.
Hugoton field – the Hugoton field is one of the largest gas fields in the US. It has produced nearly
27tcf of natural gas to date and has a high helium concentration (0.3-1.9%). As such, it has been a
substantial contributor of helium supply in the US for many years. Reports suggest there may be
another 3-4tcf of natural gas left to be produced.
Hugoton produced 97bcf of natural gas in 2016 and has declined at a five- to 10-year CAGR of
around 6-7%. We assume the entire field continues to decline at this rate. Using the field production
data (from Kansas) and applying the ranges of helium content suggests helium production
consistent with concentrations of around 0.5%. The data certainly suggest that the 1.9% upper end
of the range is not a relevant figure to use (although it may have been in parts of the field some
time ago).
Actual helium output from Hugoton is not available, but we have used the estimates of historical
data from JR Campbell and Associates from 2011-15, which imply helium concentrations of
production fell from 1% in 2011 to around 0.5% in 2015. If true, this is a concern and suggests that
our base assumption of a 6.1% decline in helium production (in line with field declines) will be too
optimistic. If the trend of falling helium concentration continues, it may be uneconomic to continue
to produce helium at Hugoton in the medium term.
Exhibit 3: Possible Hugoton helium production, mmcf/yr
3,000 2.5%
Concentration of helium from natural gas
2,500 2.0%
2,000
1.5%
production
1,500
mmcf/yr
1.0%
1,000
500 0.5%
0 0.0%
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
Concentration of helium from natural gas production Helium prodn at 0.3% concentration
Helium prodn at 0.5% concentration Helium prodn at 1.9% concentration
Assumed actual helium production
Source: Kansas Geolgical Survey, Edison Investment Research. Note: We use the 0.5% helium concentration
as a forecast guide for 2017 onwards.
1 www.gasworld.com/blm-completes-fy-2018-crude-helium-auction/2013150.article
Helium – Macro View | 19 December 2017 5LaBarge field – LaBarge is a large natural gas field in Wyoming with high concentrations of CO2
and a relatively high concentration of helium (0.6%). The field economics rely on the efficacy of the
CO2 in enhancing oil production in surrounding oil fields as LaBarge is only 21% methane (the
2
lowest methane content of any gas field globally) and is 65% CO2 (as well as 5% hydrogen
sulphide and 0.6-0.7% helium).
The Shute Creek facility separates out the gases, reinjecting the hydrogen sulphide (and some
CO2) into the reservoir, liquefying the helium and piping the rest of the CO2 to surrounding fields in
Wyoming and Colorado. The facility has a helium production capacity of 4mmcf/d, or 1.46bcf/yr,
making it a substantial contributor to global demand (around 23%).
According to Exxon, all the gas was contracted for sale since the start of operations in 1986, but
long-term sales averaged only half-capacity for much of this time, as the CO2 enhanced recovery
market did not develop as fast as anticipated, partially as a result of the distance to the fields.
Higher oil prices from the 2000s onwards made project economics more attractive. We assume that
the facility continues to produce at its capacity over the forecast period (of 4mmcf/yr or 1.46bcf/yr).
Big Piney, US (Matheson & Air Products) – Big Piney was designed to extract helium from sour
gas at rates of 200mmcf/yr, expanding to 400mmcf/yr. The helium-rich natural gas and CO2 feed
gas was due to come from the LaBarge field via Denbuy’s Riley Ridge processing plant, Wyoming.
Denbury’s interest in gas was 1.2tcf of CO2 with 0.6% helium. Indeed, Gage and Driskill (1998)
estimated helium resources of 47bcf, and peak production from the LaBarge field as a whole was
envisaged at 1.4bcf/yr. However, design issues meant there were delays to the start-up (in late
2013) and the plant was shut-in in 2014 after additional issues (caused by sulphur build-up in gas
supply wells) hampered production. The plant remains shut in and was fully written off by Denbury
in its 2016 annual report. We therefore do not expect any helium from this plant.
Doe Canyon, US (Air Products) – a helium separation plant from CO2 feed was proposed to start
in 2015 with a capacity of 400mmcf/yr, but we understand this was quickly reduced to 230mmcf/yr
after start-up and that production has declined to 140mmcf/yr currently, due to lack of demand for
the CO2 feed gas. We model that the plant continues to produce at this rate during the forecast
period, although sharp increases in oil prices could motivate greater CO2 and therefore helium (we
do not forecast this).
DBK expansion (IACX) – NASCO, a German-listed player, is planning to expand its DBK facility in
Arizona. We model production increases from 70mcf/yr in 2013 to around 150mmcf/yr in 2019.
Other – Industry sources indicate that new supply from an existing cryogenic plant in the mid-
continent US is possible over the next few years. Very little has been made public at this stage, but
we have modelled supply of 100-150mmcf/yr starting in late 2019/early 2020.
Miscellaneous – we do not have access to the production data of the other production facilities in
the US, so we assume that together they contribute around 100mmcf/yr in 2017, declining slowly
over the forecast period. These include projects by IACX (and partners) targeting helium depleted
fields and lower pressure extraction techniques. We do not see a material future contribution from
such projects.
Worldwide projects
Qatar – the start of the Helium I and II projects had a major impact on helium supply and
contributed to a surplus in 2014-16 after the shortage of 2012. The USGS estimates that Qatar
produced 1.8bcf of helium in 2016, up from 468mmcf in 2012. In theory, the helium produced
2 CO2 Management at ExxonMobil’s LaBarge Field, Wyoming, USA. P E Michael E Parker et al, Energy
Procedia 4 (2011)
Helium – Macro View | 19 December 2017 6should continue at the peak plateau rates (of around 2bcf/yr) as the production is dependent on
plateauing LNG production.
Despite the large volumes produced, estimates are difficult as no public information is available.
Indeed, in 2017 the USGS revised its 2015 production estimate from 40m cubic metres (given in
2016) to 49m cubic metres. Estimates of 2017 production are made more difficult by the recent
blockade.
The Helium III development, located in the Barzan facility, was planned to come online in 2018,
adding a further 425mmcf/yr. However, issues in the upstream mean that this may be delayed.
Such issues are often complex to fix and take some time (especially given the size of the
development). We therefore assume production comes online in Q419.
Qatar supplies c 25% of global demand and helium was exported from the UAE (via Saudi Arabia),
but this route was blocked in mid-2017. Helium production was suspended in June 2017 but
restarted in July after a new route was organised.
Russia is currently a small contributor to helium production (the USGS estimates production of just
under 110mmcf/yr in 2016) and has seen production decline steeply in recent years, as seen below.
With no further information, we assume Odenburg continues to produce at this rate, although this
could be optimistic.
Exhibit 4: Russian helium production
2,500
2,000
1,500
mmcf/yr
1,000
500
0
2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027
Russia - Odenburg Russia Russia - Amur 1 Russia Russia - Amur 2 Russia Russia - Amur 3 Russia
Source: USGS, Edison Investment Research. Note: 2017 onwards are Edison estimates.
However, the massive Amur gas development has the potential to help Russia rival Qatar as the
largest helium producer in the world by 2030. Planned to produce 42bcm of natural gas per year
(contributing to a 30bcm pa export of gas to China over 30 years), the staged development could
produce as much as 60m cubic metres of helium per year (2.2bcf/yr) – equating to 0.15% helium
concentration.
Data on the development is not easily found, but we assume helium plants come online in the
middle of 2021, 2024 and 2027, each of 720mmcf/yr. We would caution that as massive, complex
projects, it is entirely possible that the developments see delays – albeit that intense pressure will
be on managers to hit the targets given the strategic importance of the project to Russia and China
of such massive volumes of natural gas. The Amur complex will be one of the largest gas/chemicals
plants in the world. We also do not know how the constructrion of the plant will be affected by
western sanctions or exactly how it will be funded (we understand China has yet to provide some of
the substantial loans required to build the complex). The gas plant alone is currently scheduled to
cost €11.5bn.
Helium – Macro View | 19 December 2017 7Studies of projects by industry observers found that (i) 78% of upstream mega projects faced either
3 4
cost overruns or delays; (ii) 73% of projects are delayed – indeed of the 20 largest projects
5
examined by an Ernst & Young study, only seven were on budget; (iii) large oil & gas, mining and
infrastructure projects run on average 20 months late and cost 80% more than budgeted; and (iv)
the Oil and Gas Authority (in the UK) stated that fewer than 25% of new projects were delivered on
6
time over the last five years.
The impact of any delays would be very material for helium balance, as we described earlier in this
report.
Algeria supplies helium when gas from its massive Hassi R’Mel field is exported via LNG. While
the helium concentration is low (0.17%), the field accounts for c 60% of Algerian gas exports so
economic extraction is possible (no other fields have commercial helium extraction). Historically,
estimates have put helium production at around 900mmcf/yr, but we believe recently production has
been lower.
We believe Algeria prioritises its pipeline gas exports to Europe, with LNG a less critical component.
LNG volumes can therefore suffer if demand in Europe increases or gas supply in the country is not
as high as hoped.
As the crown jewel of the Algerian gas industry, the Hassi R’Mel field has taken the brunt of delays
or under-production of other fields (In Amenas, Ohanet and Reganne to take just three examples)
meaning that it has been used to fill-in these production gaps. The consequence is a reduction in
the recycling of some gas (reinjecting dry gas and stripping the liquids for sale, keeping pressure up
for longer-term reservoir management), inability to mitigate possible water production and fall in
capacity.
This is bad for helium markets as it possibly reduces ultimate recoverable helium in the long term
but also means that this in-filling of near-term gas production goes through the pipeline to Europe,
bypassing the LNG system and helium extraction. We do not know the statistics for production of
helium from Algeria directly, but instead we look to the BP Energy Review to see how LNG exports
have progressed, using rules of thumb to derive production volumes since 2010. This indicates
lower production from LNG (and consequently helium over 2010-16). Our calculated volumes
(Exhibit 4) are different to some other sources (which put exports at around 900mmcf/yr). This is a
major source of uncertainty for our analysis. For modelling purposes, we assume a 5% decline pa
in production of helium.
As the source of so much revenue, Algeria has made strides to try to better conserve the field (and
capture more gas elsewhere). It is possible that the decline in volumes in LNG may flatten out in the
near term. More work is required to maintain long-term volumes.
3
Independent Project Analysis (IPA), 2011
4
Spotlight on Oil and Gas Megaprojects, Ernst & Young
5
HIS Global Insight
6
Lessons Learned from UKCS oil and gas projects 2011-2016, The Oil and Gas Authority
Helium – Macro View | 19 December 2017 8Exhibit 5: Algeria gas volumes by export route
40 800
35 700
30 600
mcf/yr helium
25 500
Bcm/yr
20 400
15 300
10 200
5 100
0 0
2010 2011 2012 2013 2014 2015 2016 2017
mcf/yr helium LNG Pipeline
Source: BP, Edison Investment Research, various
Poland is one of the minor players in global helium, but the only European producer. According to
the Polish Geological Institute, there are 16 helium fields in the country (situated in the Zielona
Góra-Rawicz-Odolanów area) of which 14 are producing. Reserves and production are dominated
by two fields that make up almost 60% of production. The reserve life of the complex is over 30
7
years. For 2016, the combined resources were estimated to be 25.09m cubic metres and
production was 0.78m cubic metres.
This is notably different from the USGS estimate of 2m cubic metres. We take the Polish Geological
Institute figures, which show an average (10-year) yearly decline of 3.8% and assume production
continues to decline at this rate for the foreseeable future.
Exhibit 6: Polish helium production
120
100
80
60
mmcf/yr
40
20
0
1992 1994 1996 1998 2000 2002 2004 2006 2008 2010 2012 2014 2016 2018 2020 2022 2024 2026
Production Estimated
Source: Polish Geological Institute and Edison Investment Research
Other new (possible) sources
Renergen operates a natural gas field in the Virginia field in Free State in South Africa, which has
high helium concentrations (of between 2-4%) and 9.2mkg of 2P reserves (corresponding to
1.96bcf). A project to extract the natural gas over a phased development has started, but the helium
cannot be extracted until a pipeline network and central processing facility have been completed.
The latest (May 2017) estimates for this development put the helium start-up in 2019, although
delays are very possible. We currently expect the helium capacity to be around 30mmcf/yr at peak.
We note South Africa is extremely short of energy, so there are strong incentives to develop any
gas (and associated helium) over time.
Iran – the South Pars field is the same field as Qatar’s North Field and therefore could be a
massive source of helium as/when it is developed; some estimate it to contain 350bcf of helium.
7
http://geoportal.pgi.gov.pl/surowce/energetyczne/hel/2016.
Helium – Macro View | 19 December 2017 9Total’s deal with Iran (signed in July 2017) for phase 11 of South Pars envisaged 2bcf/d of natural
gas. Initial gas flows are believed to start in 2021 (for domestic market); large-scale export volumes
by pipeline/LNG may be some time after. The field already has a pipeline network so we would
think additional supplies will be exported via this infrastructure, negating the need for LNG facilities
(and therefore helium extraction plants). For LNG facilities to be built we would likely need a large
increase in LNG pricing, which we think is unlikely in the near term. Given the low concentration of
helium (0.05%) it is likely that helium production from South Pars will have to wait many years
before sufficiently large LNG facilities are built to allow commercial extraction of helium.
In this vein, on 20 November, the National Iranian Oil Company signed a contract with IFLNG to
produce floating liquefied natural gas (FLNG). The press release mentions first LNG could be
supplied before the end of 2018. Given the small volumes and the complexity of the FLNG vessel
being employed, we think it is extremely unlikely that any helium will come from this LNG supply.
There are a number of projects in Canada of differing maturities. Exploration for helium in Canada
could be very promising given proven deposits of helium in deeply buried traps, often with little
associated CO2 or other gases (other than nitrogen) making extraction and liquefaction cheaper.
Weil Group is currently producing 35-40mmcf/yr from its Mankota plant, and Medicine Hat has
announced plans to commission a facility in 2019 (of unknown helium capacity).
There are a number of players exploring (or planning to explore) for helium in Canada. North
American Helium is a private company operating in Southern Canada and has accumulated a large
property position (>500,000 acres) within a known helium province. It is seeking to further expand
its proven resource base in the Greater Battle Creek. It has so far drilled six wells, finding helium in
concentrations of around 1% (within a majority nitrogen reservoir, which makes commercialising
cheaper than if it was in a natural gas reservoir). Given the proven helium resources in the location,
we include volumes from 2020 onwards at this point.
Royal Helium Corporation is a listed vehicle focused on exploring in Canada. The company holds
399 sections (255,400 acres) of crown helium land; approximately 45% is held as helium leases on
21-year terms with the remainder held as helium exploration permits. Royal’s assets are associated
with Saskatchewan's highest known helium concentrations. The company believes its targets have
concentrations of 1.1-2.8% helium and it was planning on re-entering a well in November 2017 to
prove up its G&G analysis.
Thor Resources names five helium projects of varying maturities (from well tested to much earlier
stage). The Knappen project is believed to contain over 1bcf of helium (management estimates)
and is in development with Weil Group. We have found one source to indicate that this will be
commissioned in 2017, so timelines are uncertain at this time.
Tanzania – Helium One is a private company seeking to explore for helium in Tanzania after traces
of helium were detected in geothermal springs. According to Helium One’s website, Netherland
Sewell and Associates has estimated P50 unrisked prospective recoverable helium volume of
98.9bcf, across 28 leads (as seen on 2D seismic).
Until exploration wells are drilled, we remain cautious on the potential for commerciality of the area
– many geothermal waters around the world contain helium so this in itself is not a major indicator
3
of commercial traps. Indeed researchers posit that identifying the ratio of isotopes of helium He
4
and He from many such sites could be an indication for good locations for geothermal energy
8
plants. Historical wells by Amoco detected helium, but reservoir quality still has to be proven.
Additionally, the site is remote and the economics of liquefying and exporting the product may be
challenging.
8
Flow of Mantle Fluids Through the Ductile Lower Crust: Helium Isotope Trends, B Mack Kennedy, Matthijs
van Soest, 2007 (Science)
Helium – Macro View | 19 December 2017 10Global reserves
There is no clear picture of global helium reserves/resources and relatively little written publicly.
Many papers and books reference papers that are decades old and there are no global authorities
that publicly release data on helium in the same vein as seen in other industries.
In 2013, this uncertainty led US congress to request the USGS to perform a national and global
helium gas assessment. Given the scarcity and niche nature of helium, the USGS expects this to
take many years. However, the BLM expects to update its view on helium resources in the US in a
shorter timeframe. Discussions with the USGS indicate a report may be published by end 2018, but
this is uncertain.
Intermediate results (from January 2016) are shown in Exhibit 7. Assuming 7.0bcf/year demand
(foreseen in 2019), this would translate to 23 years of proven reserves for the US, moving out to
over 200 years including probable reserves in the US and the rest of the world. While this may
superficially seem generous, these resources have to be developed, and this is not a given.
Development of the helium is hugely dependent on the development of the gases that it exists
alongside.
Transparent reporting of reserves and resources is not helped by the tiny concentrations found in
many natural gas fields. It exists in such small quantities in many natural gas reservoirs that it is
often overlooked given the small volumes/revenues it may represent vs natural gas. Helium has
largely been a profitable by-product but not valuable enough to justify standalone developments
(nor in the US of a statute to allow federal land lease).
In most fields, large quantities of natural gas (or CO2) have to be extracted for commercial volumes
of helium to be separated, and as a result, the commerciality of a helium project largely rests
entirely away from the helium itself. As natural gas prices have declined in recent years (particularly
in the US), projects have become less attractive and fewer projects have been sanctioned.
The current surfeit of LNG supplies (and low prices) has led to postponement of large LNG
projects (such as Browse) from which other helium could have been recovered.
The low oil prices also mean that CO2 flooding (from which helium can be extracted) has
become less economic, reducing the demand for CO2. A number of projects have been put on
hold.
Shales cannot trap helium, which means that supplies have not benefited from the massive
shale boom in the US, and the economics of shale gas production have the potential to price
out conventional natural gas development (which may contain helium) in the US in the medium
term.
In the US therefore, helium development may have to be driven by helium economics, necessitating
higher helium prices to incentivise investment.
Kinder Morgan has a JV with Air Products (announced in 2013, started in October 2015) at Doe
Canyon to extract helium from the CO2 stream going to EOR projects (the plant is designed to
produce 230mmcf/year of helium but is probably producing closer to 140mmcf/yr now), while IACX
has a number of plants extracting helium from a number of small natural gas fields. Standalone
helium separation (of the type that Canadian companies are contemplating for example) requires
high helium content to be commercial (which is around 0.5%, but is highly dependent on gas
volumes and other gases in the stream).
In the rest of the world, helium production comes from large LNG schemes in Qatar and Algeria. A
planned development of a massive Russian gas field, Amur (with material associated helium), has a
risk of delays, we think.
Helium – Macro View | 19 December 2017 11Exhibit 7: Reserves of helium globally, including from Exhibit 8: USGS summary of global helium resources
natural gas fields (intermediate findings)
400 0.40% 800
Helium reserves/resources, bcf
350 0.35% 700
300 0.30%
600
250 0.25%
500
200 0.20%
Bcf
150 0.15% 400
100 0.10% 300
50 0.05% 200
0 0.00% 100
Qatar
Russia
Argentina
Algeria
Poland
Canada
Australia
US
China
0
US Qatar Algeria Russia US Canada China
Proven helium, bcf Concentration of helium in natural gas field (RHS) Proven Probable Possible Speculative
Source: BLM “BLM – Determination of fair market value pricing of Source: USGS Mineral Commodity Summaries, January 2016.
crude Helium.” Note: Proven helium reserves are given in bcf. Note: Converted using a 36cf/m ratio.
Estimates made in 2013.
Helium – Macro View | 19 December 2017 12Pricing context (BLM-era to future)
The US government-mandated sell-off of the helium reserve was designed to recoup the
investment (plus interest) on the helium reserve and get the government out of the helium market.
Initially the price set on the crude from the reserve was purely to cover the costs of the US$1.33bn
debt, and was well above the prevailing crude helium market price at the time, as can be seen in
the years 2000-05 (Exhibit 9). Helium was a profitable by-product of natural gas production, and as
such prices had little reference point, while its private nature meant price discovery was difficult.
With the advent of the BLM auction process, a partially market-driven price became public and a
reference point for private contracts. It is clear that the private spigot prices are materially above the
BLM crude pricing, with bulk liquid helium well above this level (not surprisingly given the refining
that is required). Unsurprisingly, prices rise the closer you get to the consumer, with HP cylinder
prices 2.5x the private spigot (wholesale) price.
Recent price history
BLM prices are increasingly less informative given that the auctions will shortly end as the reserve
is depleted and as helium is actually traded at much high purities. However, for reference, prices for
BLM crude have risen substantially, at an average rate of over 6% since 2007 (or over 9% in the
last four years).
Cargoes are usually sold at a 99.999% purity or Grade 5, for which we have little pricing
information. The lower Grade-A (or 99.99% purity) helium prices are estimated by the BLM to be
$200/mcf.
On 15 November 2017, Praxair announced that it will increase the price of helium from 1 January
2018 by 10% (on 1 January 2018, or by contract).
Exhibit 9: Wholesale prices of private crude helium Exhibit 10: Prices for different customers, from
converged towards rising BLM pricing wholesale (BLM and private spigot at the bottom) to
retail
200 1000
800
150
600
100 400
$/mcf
$/mmcf
200
50
0
1985 1989 1993 1997 2001 2005 2009 2013
0 HP Cylinder LHe Dewar
2000
2001
2002
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
Tube Trailer LHe Bulk
Private average BLM Est. grade-A helium price Private fob Spigot BLM Crude
Spot prices, reported
Source: USGS. Note: All prices are for crude helium The green Source: USGS, “Determination of fair market pricing of crude
range is the low to high estimates of private crude helium, and helium”, assorted sources for spot prices
estimates past 2012 are not available
Deriving a possible price trajectory from historical relationships
We could also refer to historical price relationships to give an indication as to how prices may move
in future. The charts below show a very strong relationship between US demand and pricing since
2000, though we think it is unlikely that these are causal and therefore indicative, given the long-
term offshoring of demand (mostly to Asia). We would also point out that prices (Exhibit 10) indicate
that BLM pricing is not necessarily the best indicator of end-user pricing.
Another way to look at prices is that they have risen at around a 6% CAGR since 2000.
Helium – Macro View | 19 December 2017 13Drawing analogies from other industries suffering supply
constraints
It seems likely that, should the supply/demand balance tilt as strongly to undersupply as we believe
it may, there is strong potential for upward movement to curb demand (essentially a top-down,
demand-driven pricing mechanism). This would replicate the circumstances seen in the 2011-13
shortage that led to price spikes.
While we cannot forecast prices in this scenario, it may be worth drawing an analogy to the course
of oil prices in the 2000s as spare capacity shrank and prices rose strongly from US$25/bbl in 2001,
peaking to over US$140/bbl in mid-2008. The global financial crisis then intervened, adding further
impetus to declining demand. It took up to 2014 (from 2004) for the industry to react with enough
innovation and capital to end the cycle with a powerful enough supply response.
Exhibit 11: Demand-led undersupply in 2000s caused a material move in the oil price.
8% 120
Effective spare capacity as % of
7%
100
6%
demand
80
5%
4% 60
3%
40
2%
20
1%
0% 0
2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016
Effective spare capacity as % of demand Brent price average of year, $/bbl (RHS)
Source: IEA, Bloomberg
In this scenario, the price would therefore be determined by the marginal price of demand, defined
by the maximum price users will be willing to pay for it. In the case of helium, this is very difficult to
estimate, but substitution and budgeting considerations will be key.
Looking at the uses of helium, there are areas that are obvious candidates for reduction in demand
– either because helium is substitutable with other gases, or because demand is more elastic to
price. Unfortunately, we do not have sufficiently granular detail to see clearly which industries were
most/least responsive to the 2011-13 price increases.
Exhibit 12: Demand constituents
Other Purging
14% 6% Controlled atmospheres
3%
Laboratory
10%
Leak detection
5% MRI
20%
Electronics
4%
Fiber Optics
6% Other cryogenic
4%
Breathing
Lifting/balloons 3%
8% Welding
17%
Source: Kornbluth consulting: www.kornbluthheliumconsulting.com/
Helium – Macro View | 19 December 2017 14According to the USGS, US use declined by 30% in 2013-14 and had not rebounded back to 2013
levels in 2015, despite a greater supply. This suggests a level of permanent demand destruction as
industries switched or became more efficient with supplies (many have built more effective helium
recycling facilities for example). We would flag that MRI scanners, 20% of global demand, have
seen some innovations that may reduce/negate the use of helium for super-cooling the magnets.
This is clearly a risk should these become mainstream, although it will take time for the replacement
cycle to kick in (US MRI life spans are 12 years). The comparative full-life costs of the ever more
helium-efficient technology are not yet clear and we would imagine a gradual adoption cycle as long
as helium prices do not spike in the near term.
To counter this, the pricing spike and demand destruction in 2011-13 may have left a (growing)
rump that is even less price sensitive.
Helium – Macro View | 19 December 2017 15Appendices
US Helium Extraction Act 2017
The Helium Stewardship Act (2013) set a timetable for the release of the US national helium
reserves to be steadily sold off, but did little to incentivise longer-term helium exploration. It
arguably had the opposite effect; by selling a large percentage of global demand per year to a small
number of players, it may have reduced prices below the market equilibrium. With only a few years
to go before the reserve is exhausted, steps are now being taken to motivate helium exploration
again (on federal lands).
Currently, the Mineral Leasing Act (1920) only allows companies to retain acreage if they are
extracting oil or natural gas. The Helium Extraction Act of 2017 is intended to extend these rights to
companies looking to extract helium, thereby taking a further step towards allowing focused helium
exploration. As the sponsor of the bill (Paul Cook: R-CA) stated in the House on 1 November 2017,
“[u]nder existing law, the Mineral Leasing Act only permits helium extraction as a by-product of an
existing oil or natural gas lease. As a result, if oil and gas production on a Federal site is not
economically viable, the lease will expire, regardless of the revenue brought in by helium sales. The
Helium Extraction Act of 2017 would correct this error and authorize helium production activities
where economically viable.”
The act was passed by the house (committee) without amendment in January 2017. The next step
will be to go to the Senate before being approved by the president. We do not expect this to have a
material effect on helium for a number of years, but it is nevertheless a positive step.
Helium – Macro View | 19 December 2017 16History of the BLM and the Federal Helium Reserve
In 1925, the US government started to store helium in the Bush Dome Reservoir in Texas (also
known as the Cliffside field), in order to retain reserve and flexibility on the scarce resource. Initially
set up as a strategic supply for airships, the focus moved to space exploration. As more gas was
required for the reserve, the 1960 Helium Conservation Act allowed for a 425 mile pipeline to be
built connecting a number of natural gas fields in Texas, Kansas and Oklahoma with high helium
content to the Cliffside field, where it was injected for storage. The act also funded construction of
five large natural gas processing facilities that produced crude helium as a by-product for sale to
the US Bureau of Land Management (BLM). Later, the government looked to increase the stockpile
further, and this resulted in the huge growth of reserves over the next decade, as seen in Exhibit
13. During this period, the government was the major buyer of helium.
This growth was funded by a debt to the US government, which had grown (with help from high
interest rates and inflation) to US$1.33bn by 1996. With the 1996 Helium Privatization Act,
Congress sought to recoup this amount through a controlled sale of the resource to the market,
starting a gradual depletion of the resource since then. As can be seen in the supply/demand
charts, this is a significant percentage of global supply.
It is clear that this supply will be exhausted soon. In October 2013, Public Law 113-40 (Helium
Stewardship Act) was passed, requiring the BLM to auction volumes off (to any qualified bidder), a
revision to the previous set sales price approach. In 2019, or once the resources gets to 3bcf, this
process will stop (the 3bcf will be reserved for government use). Once privately owned crude
helium has been delivered, the world helium market will no longer have the flexibility that was
historically provide by the BLM reserve.
Exhibit 13: Stocks of helium in US strategic reserve
250,000
200,000
150,000
Metric tons
100,000
50,000
0
1960
1962
1964
1966
1968
1970
1972
1974
1976
1978
1980
1982
1984
1986
1988
1990
1992
1994
1996
1998
2000
2002
2004
2006
2008
2010
2012
2014
Stocks
Source: USGS
Helium – Macro View | 19 December 2017 17Edison is an investment research and advisory company, with offices in North America, Europe, the Middle East and AsiaPac. The heart of Edison is our world-renowned equity research platform and deep multi-sector
expertise. At Edison Investment Research, our research is widely read by international investors, advisers and stakeholders. Edison Advisors leverages our core research platform to provide differentiated services including
investor relations and strategic consulting. Edison is authorised and regulated by the Financial Conduct Authority. Edison Investment Research (NZ) Limited (Edison NZ) is the New Zealand subsidiary of Edison. Edison NZ
is registered on the New Zealand Financial Service Providers Register (FSP number 247505) and is registered to provide wholesale and/or generic financial adviser services only. Edison Investment Research Inc (Edison
US) is the US subsidiary of Edison and is regulated by the Securities and Exchange Commission. Edison Investment Research Pty Limited (Edison Aus) [46085869] is the Australian subsidiary of Edison. Edison Germany
is a branch entity of Edison Investment Research Limited [4794244]. www.edisongroup.com
DISCLAIMER
Copyright 2017 Edison Investment Research Limited. All rights reserved. This report has been commissioned by North American Helium and prepared and issued by Edison for publication globally. All information used in
the publication of this report has been compiled from publicly available sources that are believed to be reliable, however we do not guarantee the accuracy or completeness of this report. Opinions contained in this report
represent those of the research department of Edison at the time of publication. The securities described in the Investment Research may not be eligible for sale in all jurisdictions or to certain categories of investors. This
research is issued in Australia by Edison Investment Research Pty Ltd (Corporate Authorised Representative (1252501) of Myonlineadvisers Pty Ltd (AFSL: 427484)) and any access to it, is intended only for "wholesale
clients" within the meaning of the Corporations Act 2001 of Australia. The Investment Research is distributed in the United States by Edison US to major US institutional investors only. Edison US is registered as an
investment adviser with the Securities and Exchange Commission. Edison US relies upon the "publishers' exclusion" from the definition of investment adviser under Section 202(a)(11) of the Investment Advisers Act of
1940 and corresponding state securities laws. As such, Edison does not offer or provide personalised advice. We publish information about companies in which we believe our readers may be interested and this
information reflects our sincere opinions. The information that we provide or that is derived from our website is not intended to be, and should not be construed in any manner whatsoever as, personalised advice. Also, our
website and the information provided by us should not be construed by any subscriber or prospective subscriber as Edison’s solicitation to effect, or attempt to effect, any transaction in a security. The research in this
document is intended for New Zealand resident professional financial advisers or brokers (for use in their roles as financial advisers or brokers) and habitual investors who are “wholesale clients” for the purpose of the
Financial Advisers Act 2008 (FAA) (as described in sections 5(c) (1)(a), (b) and (c) of the FAA). This is not a solicitation or inducement to buy, sell, subscribe, or underwrite any securities mentioned or in the topic of this
document. This document is provided for information purposes only and should not be construed as an offer or solicitation for investment in any securities mentioned or in the topic of this document. A marketing
communication under FCA Rules, this document has not been prepared in accordance with the legal requirements designed to promote the independence of investment research and is not subject to any prohibition on
dealing ahead of the dissemination of investment research. Edison has a restrictive policy relating to personal dealing. Edison Group does not conduct any investment business and, accordingly, does not itself hold any
positions in the securities mentioned in this report. However, the respective directors, officers, employees and contractors of Edison may have a position in any or related securities mentioned in this report. Edison or its
affiliates may perform services or solicit business from any of the companies mentioned in this report. The value of securities mentioned in this report can fall as well as rise and are subject to large and sudden swings. In
addition it may be difficult or not possible to buy, sell or obtain accurate information about the value of securities mentioned in this report. Past performance is not necessarily a guide to future performance. Forward-looking
information or statements in this report contain information that is based on assumptions, forecasts of future results, estimates of amounts not yet determinable, and therefore involve known and unknown risks,
uncertainties and other factors which may cause the actual results, performance or achievements of their subject matter to be materially different from current expectations. For the purpose of the FAA, the content of this
report is of a general nature, is intended as a source of general information only and is not intended to constitute a recommendation or opinion in relation to acquiring or disposing (including refraining from acquiring or
disposing) of securities. The distribution of this document is not a “personalised service” and, to the extent that it contains any financial advice, is intended only as a “class service” provided by Edison within the meaning of
the FAA (ie without taking into account the particular financial situation or goals of any person). As such, it should not be relied upon in making an investment decision. To the maximum extent permitted by law, Edison, its
affiliates and contractors, and their respective directors, officers and employees will not be liable for any loss or damage arising as a result of reliance being placed on any of the information contained in this report and do
not guarantee the returns on investments in the products discussed in this publication. FTSE International Limited (“FTSE”) © FTSE 2017. “FTSE®” is a trade mark of the London Stock Exchange Group companies and is
used by FTSE International Limited under license. All rights in the FTSE indices and/or FTSE ratings vest in FTSE and/or its licensors. Neither FTSE nor its licensors accept any liability for any errors or omissions in the
FTSE indices and/or FTSE ratings or underlying data. No further distribution of FTSE Data is permitted without FTSE’s express written consent.
Frankfurt +49 (0)69 78 8076 960 London +44 (0)20 3077 5700 New York +1 646 653 7026 Sydney +61 (0)2 9258 1161
Schumannstrasse
Helium – Macro 34b View 280 High Holborn
| 19 December 2017 295 Madison Avenue, 18th Floor Level 25, Aurora Place 18
60325 Frankfurt London, WC1V 7EE 10017, New York 88 Phillip St, Sydney
Germany United Kingdom US NSW 2000, AustraliaYou can also read
