Distribution System Synchronized Measurement Technology Deployment - Industry Roadmap Development - Project team
Project team
                                                                                                ▪   SDG&E
Distribution System Synchronized                                                                ▪   ORNL
Measurement Technology Deployment                                                               ▪   Quanta Technology

– Industry Roadmap Development

                     Trademarks are property of their respective owners. All rights reserved.                           Slide 1
Distribution System Synchronized Measurement Technology Deployment - Industry Roadmap Development - Project team
Overall Project Objectives and Approach

▪ Provide high-level guidance for development                           Roadmap for and Benefits of Deploying Sensor Technology
  and investment synchronized measurement                               for Distribution Network Modernization
  technology on distribution circuits, while                            ▪        Identify and summarize major business drivers and needs.
  looking at technical requirements and
                                                                        ▪        Industry outreach, including NASPI.
  challenges vs. industry and customer needs.
                                                                        ▪        Revise and update use cases and link them to key business
▪ The roadmap shows the activities required for                                  drivers and needs.
  successfully deploying synchronized                                   ▪        Identify system and product requirements and costs.
  measurement technology and critical                                   ▪        Develop example budgetary cost estimates for typical
  applications on the distribution systems of                                    deployment scenarios .
  SDG&E and of other utilities in other regions
                                                                        ▪        Develop example roadmaps to help utilities accelerate the
  with different needs.                                                          process - Applications, Infrastructure, and Processes.
▪ Helps DOE develop programs that can help the
  industry accelerate the grid modernization                            Pilot programs
  process by incorporating synchronized                                 ▪        Identify pilot programs for selected applications.
  measurements and systems.
                                                                        ▪        Develop benefit-cost analysis for those pilots.

                                       Trademarks are property of their respective owners. All rights reserved.                         Slide 2
Project Tasks

                                                                                                        This is where we are
                                                                                                          (NASPI meeting)
                                                 Task 1
SDG&E application
      list

                                                                       Task 2                                                                                 Task 4               Task 5            Task 6           Task 7
 Interviews with                                                                                                                   Task 3
     SDG&E
                      Identification of                                                         Detailed                                            Industry Feedback
                                                            Interviews with                                                                                                                 Identify Pilot
                     applications (App)                                                     assessment and                                         (NASPI Distribution   Industry Roadmap                     Final Report
                                          Prioritization   ComEd, ConEd and                                           Reprioritization of                                                     Programs
                      and application                                                       identification of                                          Task Team)
Literature review                                              Dominion                                                    AppGs
                       groups (AppG)                                                        high-priority App
(industry reports,                                                                             and AppG
 papers, articles,
       etc.)

Quanta Technology
 Subject Matter
    Expertise                                                Task 2 Report                               Task 3 Report

                     Task 1 Report

                                                                        Trademarks are property of their respective owners. All rights reserved.                                                                  Slide 3
Proposed Use Case and Application Grouping (1)

           Trademarks are property of their respective owners. All rights reserved.   Slide 4
Proposed Use Case and Application Grouping (2)

           Trademarks are property of their respective owners. All rights reserved.   Slide 5
Proposed Use Case and Application Grouping (3)

           Trademarks are property of their respective owners. All rights reserved.   Slide 6
Prioritization: Benefit – Cost Ratio Calculation
• Relative potential to improve          Resiliency &
  resiliency and reliability              Reliability

• Relative potential to help achieve
                                       Sustainability &
  sustainability and/or
                                       decarbonization
  decarbonization objectives
                                                                                                                         Complexity     • Relative complexity of implementing program
• Relative potential to help improve
  real-time system operation,              Real-time
  awareness, visualization and             operation
  control                                                                                                                               • Relative investment level (CAPEX & OPEX)
                                                                                                                         Investment
                                                                                                                                          required for implementing program
• Relative potential to enable             Advanced
  advanced system planning                 planning
                                                                 Benefit                       Cost                                     • Relative risk and impacts of unsuccessful
                                                                                                                              Risk
                                                                Summary                      Summary                                      program implementation
• Relative potential to improve
                                         Public safety
  public safety
                                                                                                                                        • Relative maturity of the concept and
                                                                                                                           Maturity       technology required for implementing
                                                                                                                                          program
• Relative potential to improve            Efficiency
  overall system efficiency              improvement                         Benefit/Cost                                               • Utility's familiarity with required concepts
                                                                                Ratio                                                     and technologies, and organizational
                                                                                                                          Readiness
• Relative potential to enable                                                                                                            readiness to implement and integrate
  adoption of leading industry                                                                                                            program in existing processes and activities
                                          Innovation
  practices, position utility as an
                                           potential
  innovator and/or produce
  intellectual property

• Relative potential to help become
                                            Customer
  and/or remain a trusted advisor &
                                         engagement &
  to create new services and            business potential
  products

                                                             Trademarks are property of their respective owners. All rights reserved.                                                    Slide 7
Preliminary Prioritization Results

Prioritization results were used along with potential interdependencies among AGs to develop a
proposed timeframe for implementation and overall roadmap
                                                                                                                                                                                                    TIMEFRAME FOR IMPLE
               APPLICATION                                                                                                       BENEFIT-COST    BENEFIT-COST
                                                          APPLICATION DESCRIPTION                                                                                 PRIORITY NUMBER
                 NUMBER                                                                                                             RATIO       RATIO NUMERICAL                     Yr. 1   Yr. 2         Yr. 3       Y

                  A11        High-accuracy fault detection and location                                                                              1.47               1            X       X
                  A2         Advanced monitoring of distribution grid                                                                                1.41               2            X       X              X
                  A6         Real-time distribution system operation                                                                                 1.34               3            X       X              X
                  A8         Advanced distribution system planning                                                                                   1.32               4            X       X
                  A5         DER integration                                                                                                         1.29               5            X       X              X
                  A9         Distribution load, DER and EV forecasting                                                                               1.21               6            X       X              X
                  A4         Wide area visualization                                                                                                 1.21               7            X       X
                  A17        Monitoring and control of electric transportation infrastructure                                                        1.20               8            X       X              X
                  A3         Asset management of critical infrastructure                                                                             1.17               9            X       X              X
                  A7         Enhanced reliability and resilience analysis                                                                            1.15               10           X       X              X
                  A12        Advanced distribution protection and control                                                                            1.14               11           X       X              X
                  A14        Improved load shedding schemes                                                                                          1.13               12           X       X
                  A15        Advanced distribution automation                                                                                        1.12               13           X       X              X
                  A18        Integrated resource, transmission and distribution system planning and analysis                                         1.11               14           X       X              X
                  A13        Advanced microgrid applications and operation                                                                           1.08               15           X       X              X
                  A10        Improved stability management                                                                                           1.00               16           X       X              X
                  A19        Power quality measurement                                                                                               0.94               17           X       X
                  A1         Advanced Volt-VAR Control (VVC)                                                                                         0.91               18           X       X              X
                  A16        Technical and commercial loss reduction                                                                                 0.87               19           X       X              X

                                                          Trademarks are property of their respective owners. All rights reserved.                                                                        Slide 8
Prioritization Results – Application Benefit

9.0

        8.03             7.97
8.0                                        7.79
                                                          7.54            7.49
                                                                                         7.18            7.08
                                                                                                                           6.91
7.0                                                                                                                                        6.71            6.68
                                                                                                                                                                           6.44
                                                                                                                                                                                            6.21             6.21            6.17
                                                                                                                                                                                                                                            5.98           5.96
6.0

5.0                                                                                                                                                                                                                                                                        4.75
                                                                                                                                                                                                                                                                                         4.44
                                                                                                                                                                                                                                                                                                        4.27

4.0

3.0

2.0

1.0

0.0
      Real-time      DER integration      Advanced       High-accuracy  Advanced       Advanced        Wide area         Advanced             Asset      Distribution Monitoring and       Enhanced         Improved         Integrated    Advanced     Improved load   Power quality Advanced Volt- Technical and
      distribution                      monitoring of fault detection   distribution   distribution   visualization       microgrid     management of load, DER and       control of     reliability and     stability        resource,   distribution    shedding      measurement VAR Control commercial loss
        system                         distribution grid and location protection and   automation                      applications and      critical   EV forecasting      electric       resilience      management      transmission system planning   schemes                         (VVC)        reduction
       operation                                                          control                                         operation      infrastructure                transportation       analysis                     and distribution
                                                                                                                                                                        infrastructure                                   system planning
                                                                                                                                                                                                                           and analysis

                                                                                                                      Trademarks are property of their respective owners. All rights reserved.                                                                                                                       Slide 9
Prioritization Results – Application Benefit-Cost Ratio
          9

          8                                                                                                                                        6       5
                                       High accuracy fault
                                                                                                                2
                                     detection and location
                                      (highest priority AG)               11                                                                                             12

                                                                                                                                                                    15
                                                                                                                                               4
          7
                                                                                                                                                                    13
BENEFIT

                                                                                                            9                      3

                                                                                                17
                                                                                                     7          18                                             10
          6                      8                                                      14

          5

                                                                   19
                  Technical and commercial
                                                      1
                    loss reduction (lowest
                                                          16
                          priority AG)
          4
              4                                                5                                                                                       6                           7
                                                                                                         COST

                                                                    Trademarks are property of their respective owners. All rights reserved.                                  Slide 10
Application Requirements

                                                                                                                                                                                 Minimum
  Proposed                                                                                                                                       Minimum          Maximum
                                                                  Application Group                                                                                             Report Rate
Group Number                                                                                                                                    Availability %   Latency (ms)
                                                                                                                                                                                   (Hz)
    AG1        AVVC                                                                                                                                  80             2000             1
    AG2        Advanced monitoring of distribution grid                                                                                              95             1000            30
    AG3        Asset management of critical infrastructure                                                                                           80             5000            1
    AG4        Wide area monitoring and visualization                                                                                                95             1000            30
    AG5        DER integration                                                                                                                       80             2000            1
    AG6        Real-time distribution system operation                                                                                               95             2000            1
    AG7        Enhanced reliability and resilience analysis                                                                                          80             5000            1
    AG8        Advanced distribution system planning                                                                                                 95             5000            30
    AG9        Distribution load, DER, and EV forecasting                                                                                            80             5000            1
   AG10        Improved stability management                                                                                                         99              500            30
   AG11        High-accuracy fault detection and location                                                                                           99.9             300            30
   AG12        Advanced distribution protection and control                                                                                         99.9             150            30
   AG13        Advanced microgrid applications and operation                                                                                         99              500            30
   AG14        Improved load shedding schemes                                                                                                        80             5000            1
   AG15        Advanced distribution automation                                                                                                      99              300            30
   AG16        Technical and commercial loss reduction                                                                                               70             5000            1
   AG17        Monitoring and control of electric transportation infrastructure                                                                      80             5000            1
   AG18        Integrated resource, transmission and distribution system planning and analysis                                                       80             5000            1
   AG19        PQ assessment and analysis                                                                                                           99.9            5000           120

                                                                     Trademarks are property of their respective owners. All rights reserved.                                                 Slide 11
