IP 2020: Towards a
Digital Connected Mobile Society
in the Year 2020 and Beyond
Padma Pillay-Esnault
Distinguished Engineer Future Network
padma@huawei.com
Building a Better Connected World www.huawei.com
Agenda
• Trends
• Driving Forces
• The Digital Connected Society
• IP2020 – What is it?
• Concluding Remarks
Building a Better Connected World www.huawei.com
Trends Page 3 HUAWEI TECHNOLOGIES CO., LTD.
Trends and Landscape …
The world is connecting faster than
ever before
The physical and digital world are
getting intertwined.
Page 4 HUAWEI TECHNOLOGIES CO., LTD.
Trends – Number of devices mobile vs fixed
More than half a billion (563 million) mobile devices
and connections were added in 2015
Mobility is the new norm!
By 2020 there will be 1.5 mobile devices per capita.
There will be 11.6 billion mobile-connected devices
by 2020, including M2M modules—exceeding the
world’s projected population at that time (7.8 billion).
Page 5 HUAWEI TECHNOLOGIES CO., LTD.
Trends – Traffic Mobile vs Fixed
Mobile
Global mobile data traffic grew 74 percent in 2015
Mobile video traffic accounted for 55 percent of total
mobile data traffic in 2015
Three-fourths of the world’s mobile data traffic will
be streaming video by 2020
Page 6 HUAWEI TECHNOLOGIES CO., LTD.
Driving Forces Page 7 HUAWEI TECHNOLOGIES CO., LTD.
5G Redefining Mobility experience in Future Networks
BW and Speed Latency Scale Session Mobility
5G Throughput Continuity Speed
10 Gps
5G – New opportunities for industries
Enhance Mobile Empower
Internet Internet of Things
Consumers Verticals Operators
• Ubiquitous consistent experience • Easy access to the common • Easy deployment and maintenance
infrastructure of 5G •Network flexibility for multiple
• New services
• Real-time, on-demand service industries
Page 9 HUAWEI TECHNOLOGIES CO., LTD.
Everything meets Internet Era
Intelligent
sensor
Internet IoT
100 B connections @ 2020
Mobility Cloud
computing
Page 10 HUAWEI TECHNOLOGIES CO., LTD.Long Tail Use Cases Drive 5G Technical Requirements
New Use Cases + New Business Models
Video
Web 1ms 10Gbps 1M
Latency Throughput Connections/Km2
Traffic/Revenue
Voice Vehicular
Telematics
Massive IoT
AR/VR
MirrorSys High Speed Tele-
Railway operation
……
Use Cases
Body The Long Tail
Page 11 HUAWEI TECHNOLOGIES CO., LTD.Newer Applications - Multidimensional Requirements
Requirements are actually n-dimensional
Low power device
Security
Context awareness
Retention of profile
Single signon
QOS
Session continuity
….
Source: Huawei – 5G: A technology Vision
Page 12 HUAWEI TECHNOLOGIES CO., LTD. The Digital Connected Society Page 13 HUAWEI TECHNOLOGIES CO., LTD.
Mobile Data Services as a Pillar to New Experiences in 2020
Near Reality Tele-surgery Robot Assisted Care Connected Cars Drone delivery
Experience Collision avoidance
Internet Of Immersive Tactile Smart Artificial
Things Technologies Networks Mobility Intelligence
Wearables, sensors, Industrial
Monitors Robots
No
Always On Pervasive Near Zero
perceived
bandwidth Latency
data loss
Page 14 HUAWEI TECHNOLOGIES CO., LTD.Imagine ….
Enable Vertical
Industries
Industry level: Embrace opportunities and transformation in a
Digital Connected Society
Enhance Improved
Connectivity/ BW User
Enable Ubiquitous Experience
Access
Page 15 HUAWEI TECHNOLOGIES CO., LTD.Always connected
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo
Page 16 HUAWEI TECHNOLOGIES CO., LTD.Connected Cars
Page 17 HUAWEI TECHNOLOGIES CO., LTD.
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0BoIntelligent Transport Systems
Page 18 HUAWEI TECHNOLOGIES CO., LTD.
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0BoSmart Agriculture Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo Page 19 HUAWEI TECHNOLOGIES CO., LTD.
Tele-Healthcare
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo
Page 20 HUAWEI TECHNOLOGIES CO., LTD.Augmented Reality
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo
Page 21 HUAWEI TECHNOLOGIES CO., LTD.Virtual Reality Source pic http://www.rmmagazine.com/wp-content uploads/2014/09rm10.14_virtualreality.jpg http://www.businesswire.com/news/home/20160303005342/en/Flags-Magic-Mountain-Announces-North-America’s-Virtual Page 22 HUAWEI TECHNOLOGIES CO., LTD.
Smart House/City
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo
Page 23 HUAWEI TECHNOLOGIES CO., LTD.Smart Industry
Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo
Page 24 Source Huawei:https://www.youtube.com/watch?v=4z9i4q5t0Bo HUAWEI TECHNOLOGIES CO., LTD. IP 2020 Page 25 HUAWEI TECHNOLOGIES CO., LTD.
What’s the next gen network?
Everything is …. The Bliss Point is ….
Technology Aspect
Simpler
Virtualized Faster to deploy
Mobile
Financial Goals
Connected
Almost zero-touch config (less
opex)
Virtualized (Less capex)
Everything over anything
Mobile (commodity HW)
User Experience
Self-Aware Accessible anywhere
New Experience
Fast and smart services
Self aware apps
Page 26 HUAWEI TECHNOLOGIES CO., LTD.What IP 2020 Delivers?
Ability to Cross-
connect diverse IOT High-throughput
Trillion Ultra transport delivering
networks at scale.
Of Things AR/VR super media
Mobility-
Embedded
Mobility IP 2020
Omni
Present
Self-
Organizing Self managing,
autonomic networks
Secure connections Trustwort
across everything hy Network
Page 27 HUAWEI TECHNOLOGIES CO., LTD.Tomorrow’s needs and today’s network …
The adoption of 5G with its new requirements are The Internet was originally designed as a static
going to challenge the infrastructure. network.
Scale The EPC/RAN interconnects with the core IP
Mobility (large range and fast) network - hybrid of 2 Architectures
High throughput and low latency Good enough for 5G and beyond?
Security o Scale with more density?
Self- Aware/Managing Network o Bigger ―pipes‖ & Faster CPU vs Green
o Context Awareness?
Energy preservation and low power o Identity Awareness?
consumption for devices o Session continuity?
Deployment over a heterogeneous
Access
Session continuity
Page 28 HUAWEI TECHNOLOGIES CO., LTD.ID Oriented Networks in a nutshell
Basics Properties
Principle : Need to dissociate the Native mobility
name and location and make them Apps can be based on ID
independent. Addresses multi-homing ID have
ID can be the name of a node, an app global significance( scope),
or anything Context awareness based on ID
The Identifier movement is profile
transparent to the higher layers. Security also can be ID based
The forwarding is achieved by Fast deployment – Reuses already
binding the ID with an ip address or deployed and working (if IP)
locator.
One user can have multiple IDs
Page 29
or
HUAWEI TECHNOLOGIES CO., LTD.ID-Oriented Networking (ION) Application0 Application0
L4 TCP/UDP L4 TCP/UDP
L3.5 ID
ID Plane L3 IP
L3 IP
Unified ID Management (User ID, Host ID, Content ID, VN ID)
L2.5 MPLS L2.5
User Management (Authentication Business, Usage MPLS
and Delegation) and Charging L2 Access L2 Access
ID-Locator Mapping System Policy Control Technology Technology
Locator Plane No need for clean slate
Reduced Capex and Opex
Unified Access Gateway
Global Reachability Possible: Everything, allocated with a unique ID,
Innovation Speedup：Locator plane as a transport layer, while ID
plane as a service and business layer. New services and business can
Access
Wireless
Non-3G__
DSL Access
Fiber Access
Access
3GPP Wireless
IOT Access
be developed on top of ID without changing the underlying locator
plane.
Map and Encapsulate packets which can run on an IP core
Page 30 HUAWEI TECHNOLOGIES CO., LTD.ION Unlocks New Opportunities Beyond Mobility
Mobility Benefits and Opportunities
ID Based Mobility
Context Aware
Security based on ID
Communication
Delivers Better Service Experience
P2P Communications without servers
Optimal traffic path selection
Cross-silo communication possible
No detours to mobility anchor point
ID based Group-communication (PIM free)
Simplified Network Operations
Accelerated applications deployment
Unified ID plane for any fixed and
Network/Topology change agnostic
mobile access
Focus on business logic not network
ID Agnostic Stable Core
Refined Edges
FIB remains locator based
Fine grained ID aware TE, Policy, LBs
As user moves, no route change
ID based End to End Security
triggers
Page 31 HUAWEI TECHNOLOGIES CO., LTD.Throughput Matters!
5G
5G
© Padma Pillay-Esnault
User experience is more related to the session throughput.
The session throughput is dependent on TCP which is an end to end solution
Links of varying quality can be perceived by TCP as congested causing unnecessary throttling
Throughput issues which will not work for UHD and other sensitive applications
Page 32 HUAWEI TECHNOLOGIES CO., LTD.Self-X Network for Intelligent Edge
IP Core
Massive
Connections Intelligent Edge
（100b by 2025）
Network modeling based IT
Self- service and network node auto-
Learning connect
Light-weight
network
Protocol and algorithm for self-
Self- Self- organization network
Healing Config
Self-organized
network Self-X
Auto detect, self protect for
network attacking
Thing to Self- Self-
thing connect Optimization Organization Auto monitoring, self-repair for
network defects
Page 33 HUAWEI TECHNOLOGIES CO., LTD.Self-X Enterprise Network:Zero config/maintenance
Production R&D Market
From Network Model for IT
Inter connected Devices services
Auto Authorize Connectivity
In Network Permission
Checks
Intelligent
Self-
Enterprise
To Desired Network Organizing Network
topology
Switchboard
Big data analysis
Current capacity Jam
Uses Big data analysis ….
from maintenance DDOS DDOS DDOS DDOS
Big data analysis
Eliminate Human Interaction. Move towards Big Data Analysis and Automatic Defense Automated
Against Attack Congestion Control
Automation
Page 34 HUAWEI TECHNOLOGIES CO., LTD. Concluding Remarks Page 35 HUAWEI TECHNOLOGIES CO., LTD.
IP2020
Applications Requirement Today IP2020 proposals
IOT Scale IPv6 proposal for IOT ID can be anything, free
format from string to
ipv4, ipv6, coordinates,
names, temporary Id …
Mobile devices Mobility with low latency IP mobile solutions have ID dissociation between
triangular routing issues Identity and location in IP
Smart delocalized MS
AR,VR,4k 8k video High Throughput TCP has end to end Need to change
congestion which transport
impacts the throughput Under discussions
Transactions, Privacy Security Ipsec solution expensive Native Security in
and not desirable network DNA.
Encryption.
Low maintenance, self Self Aware/Self Healing none Self-X, Machine learning
organizing network …
Page 36 HUAWEI TECHNOLOGIES CO., LTD.Where are we at regarding standards?
• 5G will intersect with many technologies
• A practical approach is necessary to aim for a deployment in 2020.
• It is a unique opportunity to have a holistic view and to simplify/flatten the topology.
• Mutliple Standard bodies are working on different aspects
IETF/IRTF
3GPP
ETSI NGP
Page 37 HUAWEI TECHNOLOGIES CO., LTD.The timeline for 5G (3GPP) Page 38 HUAWEI TECHNOLOGIES CO., LTD.
Protocols for IP 2020: A Summary
Transport
Layer
ID
Layer
Network
Layer
Page 39 HUAWEI TECHNOLOGIES CO., LTD.Thank you
www.huawei.com
Copyright©2015 Huawei Technologies Co., Ltd. All Rights Reserved.
The information in this document may contain predictive statements including, without limitation, statements regarding the future
financial and operating results, future product portfolio, new technology, etc. There are a number of factors that could cause actual
results and developments to differ materially from those expressed or implied in the predictive statements. Therefore, such
information is provided for reference purpose only and constitutes neither an offer nor an acceptance. Huawei may change the
information at any time without notice.
Page 40 HUAWEI TECHNOLOGIES CO., LTD.You can also read
