Electric Submersible Sewage Pumps
Ranges AM, AV
Discharge Size
3‘‘ – 6‘‘
InnovationinHydraulicPerformance
1
The source for high efficiency
High Performance
in Waste Water Pumping
Flexible system-components The reliability of fully automatic
for problem-free installation operation
HOMA submersible waste water and HOMA combines efficiency, safety, HOMA waste water pumping stations
sewage pumps operate worldwide high quality and robust design with feature fully automatic control and
in numerous kinds of domestic, a flexibility that allows the individual monitoring. Reliable liquid level control
municipal and industrial applications. optimization of every project realization: systems of various types (float switch,
Decades of experience in the design Pumps for various types of application pneumatic, ultrasound or electronic
and manufacturing of submersible and installation, a complete program of systems) are available to secure reliable
pumps plus uncompromising attention installation equipment including pipes, pump operation at minimum energy
to quality in every detail and strict valves, pump pits from concrete or consumption. All possible fault factors
monitoring ofproduction quality ensure composite materials, electric control like shaft seal condition, temperatures,
the utmost reliability and long service and monitoring systems. With this moisture or power supply can be
life of all HOMA products. range HOMA can provide a tailor -made automatically monitored and transferred
solution for every waste water pumping to various alarm systems.
application.
2
The source for extraoptions and applications
Higher Performance
to meet every Challenge
Various challenges – individual solutions:
HOMA submersible wastewater
pumps are designed for pumping
sewage, sludge, effluents or surface
water, including liquids containing a
large proportion of solid or fibrous
matter. They are installed in domestic,
municipal, industrial and agricultural
pumping applications.
For chemically aggressive liquids,
specific components like impellers,
volutes or complete units are also
available from high-resistant materials
like stainless steel, duplex or bronze.
The right installation for every pump station
Wet well installation with Wet well installation with base stand Operating conditions
auto-coupling system
Submerged autocoupling guide tube Submerged pump mounted The motors are designed for
system for automatic connection and on a ring base stand for continuous operating duty (S1) at
disconnection of the pump from the temporary, service or maximum 15 starts per hour. In
pipework from outside the sump. emergency operation. addition to a fully submerged motor
All maintenance or repair work can Discharge connection with housing in wet well installation, a
be done outside the sump. Back in pipe or hose. jacket cooled motor-variant is available
operating position, the weight of the for S1 operating with a non-fully
pump ensures leak-proof discharge submerged motor or for dry well
Permanent dry well installation, installation.
connection.
vertical or horizontal
Pumps with enclosed two-channel
Flood-proof impellers are designed for intermittent
installation for operation, normally in automatic
pump stations levelcontrolled wet or dry well sump
with separate installations. They are also suitable
collection sump. for limited continuous operation, as
Fixed flanged in storm water retention tanks, or for
connection of unlimited continuous operation, such as
suction and industrial water supply.
discharge pipe.
3
The source for increased safety and reliability
Design - Proven Quality
in Detail
More quality in design and materials Materials
– less maintenance and failures
Motor housing ASTM A 48; CI.40 B 1)
Quality can be measured – HOMA Pump housing ASTM A 48; CI.40 B 1)
submersible waste water pumps are
ASTM A 395
characterized by the robust design,
generous dimensioning and high quality Impeller ASTM A 48; CI.40 B 1)
materials of all components. ASTM A 395
Wear rings Bronze / Stainless Steel
Motor shaft Stainless steel
Mechanical seals Silicon-carbide / Silicon-carbide
Motor cooling jacket (model U) Stainless steel
Seals and O-rings NBR (Perbonane) 3)
Cable H07RN-F (PLUS) 4)
1) also available in stainless steel 3) also available from FPM (vitone)
2) also available in bronze 4) screened cable on request
Discharge Motor cooling Thermal sensor (bi-metal)
With DIN/ANSI flange 3‘‘ up to 6‘‘ Motors for submerged operation Embedded in the motor winding.
are cooled by the surrounding liquid. PTC sensors available on request.
Non-clogging, For dry well or non-submerged
high efficiency impellers operation, motors are available with Moisture monitoring
With large spherical clearance. in stator housing
a cooling jacket, arround the motor.
Available: 3 Systems are alternatively available: Available on request.
• Enclosed single channel impeller
• The standard system provides a Shaft bearing
with replaceable wear ring.
cooling circulation of water from the Maintenance-free,
• Vortex impeller.
pump volute (pump model code: U) prelubricated ball bearings.
Shaft seals • Option 1 provides a cooling
Two independently working circulation by an external cooling Temperature monitoring
siliconcarbide mechanical seals in liquid system (fresh water or of the shaft bearings
tandemarrangement. radiator) trough inlet and outlet Available on request.
connections at the motor jacket
Oil chamber Cable junction chamber
(pump model code: UE)
Separate large oil chamber, Separate junction chamber standard
lubricating and cooling the • Option 2 is a closed circuit cooling from 13 HP-4 pole, below on
mechanical seals, forming an extra system with a cooling liquid request.
safety and inspection element. internally circulating, providing the
Additional electronic seal condition heat exchange through a contact Electronic moisture sensor in
monitoring probe on request. surface between heat exchange junction chamber
chamber and pump chamber. Available on request.
Motor
Three-phase electric motors, with Pressure sealed,
2-, 4- or 6-pole motor speed. strain relief cable entry
Insulation class F (155 °C), degree of
protection IP 68
Explosion protection
All models available with Factory
Mutual (FM) label for Class I, Div 1
Ex construction.
4
�
Option 1
� External cooling system
inlet and outlet for external cooling liquid supply
�
�
�
�
� Option 2
Closed circuit cooling system
� backflow of hot inflow of cold cooling
� cooling liquid into liquid into motor
heat-exchange jacket chamber
chamber
�
� �
� �
small impeller for heat exchange of
� � pumping the cooling cooling liquid with cold
liquid pumped liquid through
pump flange, spiral-shaped
for maximum surface
�
�
5
Ranges and Models
Motor selection
Motor speed: Type of starting: Motor monitoring:
For the standard hydraulic ranges, the The motors are supplied as standard All motors are supplied with
motors are designed with the following suitable for Direct- or Star-Delta-Start. temperature sensors in the winding,
speeds: All motors are also suitable for operating bi-metalic sensors (standard) or PTC
• 3450 rpm = 2-pole with frequency converter or soft starter sensors (on request).
• 1750 rpm = 4-pole device.
• Motors for wet well installation
• 1160 rpm = 6-pole
Explosion protection: (without cooling jacket):
Voltages: As C-version (see pump type code)
In addition to the standard version, all
with oil chamber seal condition
All specified data relate to an operating motors are available explosion proof
monitoring probe and moisture
voltage of 230 V / 460 V, 3 Ph, 60 Hz. according to Factory Mutual (FM) label
sensor in junction chamber)
Different voltages are available on for Class I, Div 1.
request. • Motors with cooling jacket:
Dry well variant: Supplied as standard with oil
Besides the version for submerged chamber seal condition monitoring
operation, all pumps are also available probe. S-version additionally with
for dry well or non-submerged moisture monitoring in the stator
operation. housing.
Additional monitoring devices (e. g.
bearing temperature) on request.
Hydraulic selection
Discharge and suction flange: Enclosed single channel impeller
• 3‘‘ For liquids containing impurities and
• 4‘‘ sludge with solid particles or long fibres.
• 6‘‘
Reducing adapters for different
autocoupling system and valve
dimensions are available.
Impeller spherical clearance:
The pumps are available with impeller Vortex impeller
spherical clearances from 3‘‘ to 4‘‘
according to pump range. For liquids containing a high level of
impurities or fibrous matter and contain-
ing gas.
6
7
The source for worldwide
pumptechnology
International
Customer Service
Worldwide Presence Network of Sales and HOMA product range
Service Partners
HOMA pumps are installed in more HOMA provides a · Submersible waste water pumps with
than 60 countries around the world – worldwide network channel- and vortex-hydraulic
in countless projects of various kinds. of agents and dis- · Submersible propeller pumps
They comply to all international safety tributors support- · Submersible grinder pumps
and quality standards and are certified ing our customers · Submersible, surface and venturi
by many institutions and organisations with excellent aerators
responsible for national waste water sales and service assistance in planning, · Packaged pump stations
treatment standards. To maintain and specification and selection, including a · Waste water lifting stations
further develop this high quality level computer software program available on · Submersible drainage pumps
is our main target. CD-ROM or from the WorldWideWeb. · Contractor pumps
· Submersible mixers and flow
generators
· Electric and electronic pump controls
HOMA Pumpenfabrik GmbH
P.O.Box 22 63, D-53814 Neunk.-Seelscheid
Tel. +49 (0) 22 47 /702-0, Fax +49 (0) 22 47 /702 -44
e-mail: info@homa-pumpen.de
www.homapumps.com
We reserve the right to alter our specifications without notice!
